HOT SALE! JMC 156hp diesel 2tons telescopic crane boom mounted on truck for sale, JMC double cabs truck with crane
HOT SALE! JMC brand 4*2 LHD 156hp diesel 2tons telescopic crane boom mounted on truck for sale, JMC double cabs truck with crane for sale
CLW truck mounted crane is one of our main mature products which is also named hydraulic truck crane, mobile crane, truck mounted crane, lorry-mounted crane, lorry crane, truck with loading crane, truck cargo crane and so on. It is widely used in various loading and unloading, installation and lifting, especially in the field of outdoor lifting, salvage operation and other narrow places such as station, port, warehouse and construction site.
Product Notes of CLW brand truck mounted crane manufactured by Chengli Special Automobile Co., Ltd. as below.
· Optional: from 2 ton to 200 ton lifting capacity crane truck
· Optional: straight arm and floding arm truck crane with or without remote control
· Optional: different famous crane brand: HIAB, Shimei, Zoomlion, Sany, Chengli balong, etc.
· Optional: different famous chassis brand: Dongfeng, FAW, Foton, Sinotruk, Syter, Shaanxi, T-king, Dayun, Yuejin, JMC, JAC, etc.
· Factory direct sale, low price and good quality.
The truck-mounted craneis also called crane truck, truck mounted crane, truck crane, truck with crane, etc. The truck-mounted crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc.
Chengli Special Automobile Co., Ltd., as a professional truck-mounted crane manufacturer in China, the truck-mounted crane for sale is from 2 ton to 32 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.
If you're interested in our truck with crane, please kindly send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
JMC brand 4*2 LHD truck with crane adopts JMC double cab driver cab, 3360mm wheelbase, 2tons front axle/ 4tons rear axle, 7.00R16 rail tires, 5 speed gearbox, JX493ZLQ5 85KW 116hp diesel engine, etc.
The overall dimension of JMC Brand 4*2 LHD 2tons knuckle crane boom with truck is 5995×2060,1890×2900,2590(mm), and the cargo body dimension of JMC Brand telescopic crane boom mounted on truck is 2700×1800×380(mm).Client choose to install CLW Brand 2tons telescopic crane boom.
More pictures of JMC brand 4*2 LHD 2tons knuckle crane boom mounted on truck manufactured by Chengli Special Automobile Co., Ltd. as below.
The specification of JMC 2tons knuckle crane boom mounted on truck as below
| Product name | JMC Brand 2tons knuckle crane boom mounted on truck | |
| Truck chassis | JX1041TSG25 | |
| Parameters | Overall dimension length/width/height (mm) | 5995×2060,1890×2900,2590 (mm) |
| Cargo body dimension (L*W*H)(mm) | 2700×1800×380 (mm) | |
| GVW(kg) | 4495 (Kg) | |
| curb Mass(kg) | 3530,3325 (Kg) | |
| Rated mass(kg) | 640,845 (Kg) | |
| Approach angle/ Departure angle(mm) | 27/14.7 (°) | |
| Front suspension/rear suspension(mm) | 1065/1570 (mm) | |
| Fuel Type | diesel | |
| Max Speed | 100 | |
| Engine | Type | JX493ZLQ5 |
| Displacement/Power(kw) | 2771ml/85KW/115hp; | |
| Manufacturer | JIANGXI wushiling | |
| Chassis | Drive Type | 4×2 |
| Wheelbase(mm) | 3360 | |
| Tread(front/rear) | 1385/1425 | |
| Transmission | 5 speed transmission, manual | |
| Braking system | Oil cut braking | |
| Cab | JMC double cab driver cab | |
| Number of spring axle(front/rear) | 7/4+6,7/5+6 | |
| Tire Type | 7.00R16 rail tires | |
| Air-condition | Choose to fix | |
| Upper part(cargo van and crane boom) main parameters | ||
| Upper body | Cargo body dimension | 2700×1800×380 (mm) |
| Material | Carbon steel | |
| Side sheet thickness | 2mm thickness | |
| Bottom sheet thickness | 2mm thickness | |
| Painting | Upon request | |
| Crane boom main parameters | ||
| Crane boom | Choose to install CLW brand 2ton knuckle boom | |
| Rotation degree | ±360°full rotation, full hydraulic | |
