FAW brand RHD diesel road sweeeping vehicle for sale, Factory sale good price street sweeper vehicle
Features:
1.Main material of tank use Q345 steel,high strength,compared with ordinary steel materials,under the same thickness
increase 60% strength than ordinary low carbon steel;Tank use epoxy anti-corrosion material handling,
great corrosion resistance, greatly extending the life of tanker.
2.Using Hangzhou Veyron sprinkler pumps,with characteristics of output power
and high pressure .
3.Sprinkler system install manual valves and pneumatic valves,both manual and automatic control can be used,tank Install alarm system of
low water level to prevent damage to the pump because of water shortage.
4.Tank is equipped with a spacious rear platform, people can operate on thestage, the use of high-pressure spray gun with a long-range, can do long-range spraying operations,High pressure spray gun nozzle can be
achieved by manually adjusting the water column, mist spray, mist,heavy rain and
light rain to meet different needs.
high-pressure water system:
Before cleaning device’s cleaning width 2.5m ~ 3.5m, we can control, when the adjustable spray rod shrink,
to achieve enhanced the dual water wash.
Using natural gas vice engine to drive high pressure pumps and working device hydraulic system, high pressure cleaning
speed can be controlled at will.
Liquid, gas central control, has good man-machine interface, operation can be convenient and flexible.
Use of international brand-name high-pressure pumps, reliable performance,
long life, ensuring the cleaning effect; inlet nozzle, jet stability, low pressure loss.
Using modular combination design, implement a variety of cleaning functions and auxiliary work function, a multi-purpose machine.
Spray on left and right angle is suitable for efficient water-saving ground pavement,
curbs, guardrails isolation belt, sidewalks.
High pressure spray gun not only can be use clear signs, billboards, etc.; but also can spray dust,adjust air
humidity and spray air disinfectant.
technical parameters of CLW Brand road sweeper truck as below.
Technical parameters of 4x2 diesel FAW sweeper truck for sale
| Items | Descriptions | Specifications and Types |
| General | Truck Name | Road sweeper truck |
| Drive Type | 4*2 | |
| Gross Vehicle Weight(kg) | 8280 | |
| Curb Weight(kg) | 5300 | |
| Overall Dimensions L*W*H(mm) | 6540×2160×2650 | |
| Engine | Engine Brand | FAW |
| Fuel Type | Diesel | |
| Power | 90KW/120HP | |
| Emission Standard | Euro III | |
| Displacement(ml) | 3168 | |
| Engine Type | 4 cylinders in line,4 stroke, water cooling, charged diesel engine, inter-cooling | |
| Chassis | Chassis Brand | FAW |
| Cabin | Flat roof, single row cab, with air conditional | |
| Tire No. | 6+1 | |
| Tire Specification | 7.50R16 Steel tire | |
| Wheelbase (mm) | 3860 | |
| Axle No. | 2 | |
| Gear Box | 5 speed forward with 1 reverse, manual | |
| Brake | Air brake | |
| Steering Wheel | left hand drive, right hand drive is optional | |
| Sweeping System | Dust tank volume(m³) | 5 |
| Water tank volume(m³) | 2.5 | |
| Tank material | SUS304 stainless steel | |
| Sweeping width | More than 3m | |
| Sweeping capacity | About 45000m2/h |
