HOT SALE! 2021s new ISUZU 700P 190HP Euro 6 diesel bbay chick transported vehicle, 6.8m length baby chick van truck
HOT SALE! 2021s new ISUZU 700P 190HP Euro 6 diesel bbay chick transported vehicle, Good price 6.8m length baby chick van truck for sale
Day old chciks transported truck is also called baby chick truck, young chicks transported truck. There are several electronic ventilator fans on the top, and the left-right sides with several slidable windows to keep air ventilated. There is cooling reefer, adjusted the temperature freely, suitable for transporting farm poultry, etc. It is mainly for professional transporting day old chicks, day old ducks, baby goose, flowers, seedlings, etc. a good tools to improve efficiency and reduce transporting cost. The advantages of the day old ducks truck are rainproof, dustproof, theft-proof, environmental protection, high efficiency, ventilating, insulation, large loading capacity, etc.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of van truck in China. With many years’ development, Chengli Special Automobile Co., Ltd. could supply refrigerated truck, insualtion body van box, cargo van truck, baby chick transported truck, etc. And our CLW brand van truck have been exported to many countries all over the world. More information, please feel free to contact with Ms. Anita.
If you're interested in our day old chick transported van truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
More pictures of ISUZU brand 700P Euro 6 diesel engine baby chick transported truck manufactured by Chengli Special Automobile Co., Ltd. as below.
ISUZU brand 700P series day old chick transported truck, adotps high quality 700P single row reserible driver cab with power steering and air conditioner, ISUZU MLD 6 speed gearbox, 5200mm wheelbase, 4HK1-TCG61 Euro 6 190hp diesel engine, 4tons front axle/7tons rear axle, ABS, air cut braking, 235/75R17.5 tires,
The technical parameters of upper part for dongfeng D9 as below
The cold van body dimension of Dongfeng D9 day old chicks transported carrier is 6860*2100*2000 (mm). The interior and exterior of the van box body with fiber reinforced plastics(FRP), and the middle insulation layers of 80mm thickness PU foam. There are sliding windows and waterproof blind-windows. The air will be from the van body floor ventilation
Left and right sides of the van body are with 12 sets 40*40 Mesh Plates for the cold air from the reefer. There are several 320*320 electronic ventilator fans mounted on the truck top and the rear door plate. Folding Shelves are for the two sides van body. Both Two sides of the van body with 5 blind-windows; while top mounted sky-window. Three lines of ventilator Air Ducts mounted on the van floor. The reefer choose high quality China made engine-powered refrigerator( the lowest temperature inside the cold room box up to -10℃, adjusted at the driver cab). The heating system is selective.
The technical parameters of ISUZU 700P LHD 4*2 day old chick transported truck(CLW5110XCQQ6) manufactured by Chengli Special Automobile Co., Ltd. as below.
| Product name | ISUZU 700P LHD 4*2 day old chick transported truck(CLW5110XCQQ6) | ||
| Overall dimension(L*W*H)(mm) | 8970*2260*3310 | Chick van box dimension(L*W*H)mm | 6860*2100*2000 (mm). |
| Drive type | 4*2 LHD | Total mass | 10550kgs |
| Curb mass | 5680kgs | Rated mass | 4675kgs |
| Gearbox | ISUZU MLD 6 speed transmission, manual | Tyre specification | 8.25-16 nylon tires |
| Power steering | Yes | Front/rear axle | 4tons/7tons |
| Oil braking | Yes | Driver cab | Isuzu 700P single row driver cab with air conditioner |
| Engine | 4HK1-TCG61 | Emission standard | Euro 6 |
| Engine type | Isuzu 190hp diesel engine | ||
Main parameters of chick baby van box body as below
| Performance and consumption | ||
| Heating system | Watering system | Without, client choose to install |
| Cooling system | One reefer | USA brand THERMO KING vehicle-powered refrigerated reefer( the lowest temperature inside the cold room box up to -10℃, adjusted at the driver cab) |
| Ventilation system | Air duct installed on the floor for air flow | Two/three line as the pictures show |
| Blind windows | 6 sets of blind windows with sliding doors for the left and right van sides (as the pictures show), Windows: 6*2 = 12 windows |
|
| electronic ventilator fans | 6 sets of electronic ventilator fans on van top; 4 sets for the back door. Electronic fans: 6*2+4=16 fans |
|
| Sky-window | Top mounted sky window* 4 sets sky-windows | |
| Dimension | ||
| Chick van box body | Length | 6860mm |
| Width | 2100mm | |
| Height | 4675mm | |
| Material | Exterior and interior | High quality with whole skeleton of the SANDWICH plate bonding process. Inner plate use high quality fiberglass and exterior plate with Fiberglass Reinforced Plastic (FRP) |
| Middle insulation layer | Middle insulation layer with high quality 80mm PU foam sheets. | |
| Chicks nos. | About 40,000chicks | |
