Customized SHACMAN 8*4 LHD 16tons telescopic truck with crane for sale, HOT SALE!21.7m telescopic boom mounted on truck
Customized SHACMAN brand 8*4 LHD 14T telescopic crane boom mounted on cargo truck for sale, 21.7m working radius truck with crane for sale
The cargo crane is also called truck mounted crane, crane truck, truck with crane, etc. The truck with crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc
As a professional cargo truck crane supplier in China, we Chengli Special Automobile Co., Ltd. manufacture the crane boom is from 2 ton to 160 ton. The drive type of our truck crane for sale are 4x2, 6x2, 6x4,8x4,etc. The truck mounted crane for sale are telescopic boom truck mounted crane, knuckle boom truck mounted crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc. The crane for truck can be crane, chengli crane, sany crane, unic crane, kanglim crane, etc.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.:+86 13329899995.
Website: www.trucksinchina.com
More pictures of SHACMAN brand 8*4 LHD 16T telescopic crane boom mounted on cargo truck as below.
Customized SHACMAN brand 8*4 LHD 16T telescopic crane boom mounted on cargo truck adopts Shacman M series low-top luxurious driver cab, 2100+4575+1400mm wheelbase, SHACMAN brand 8*4 LHD 16T knuckle crane boom mounted on truck for sale, 10JSD180+QH50 gearbox, WP10.380E22 380hp diesel Euro 2 engine, MAN 9.5T front axle, 400L aluminum alloy tanker, 12.00R20 rail tires, etc.
Clients choose to install CLW Brand high quality 16tons telescopic crane boom. The cargo body dimension (L*W*H): 8000x2450x600 (mm). There are rear manual ladders at the rear part of the cargo body. Choosing to install XCMG brand 14T knuckle crane boom (the max working height is 23.3m and the max working radius is 21.7m).
The specification of SHACMAN brand 8*4 LHD 16tons telescopic crane boom mounted on truck as below
| Product name | SHACMAN brand 8*4 LHD 16tons telescopic crane boom mounted on truck for sale | |
| Chassis type | SX1310 | |
| Parameters | Overall dimension length/width/height (mm) | 12000×2550×3980 |
| Cargo body dimension (L*W*H)(mm) | 8000×2450×600,800 | |
| GVW(kg) | 31000 (Kg) | |
| Kerb Mass(kg) | 20800 (Kg) | |
| Rated mass(kg) | 10070,10005 (Kg) | |
| Approach angle/ Departure angle(mm) | 16/10 (°) | |
| Front suspension/rear suspension(mm) | 1525/2400 | |
| Fuel Type | diesel | |
| Max Speed | 90 | |
| Engine | Type | WP10.380E22 |
| Displacement/Power(kw) | 9726ml/280KW/380hp | |
| Manufacturer | WEICHAI | |
| Chassis | Drive Type | 8*4 |
| Wheelbase(mm) | 2100+4575+1400 | |
| Tread(front/rear) | 2036/2036, 1860/1860 (mm) | |
| Transmission | 10JSD180+QH50 manual gearbox | |
| Braking system | Air braking | |
| Cab | SHACMAN M3000 luxurious driver cab | |
| Number of spring axle(front/rear) | 10/10/12 | |
| Tire Type | 12.00R20 | |
| Upper part(cargo van and crane boom) main parameters | ||
| Upper body | Cargo body dimension | 8000x2450x600 |
| Material | Carbon steel | |
| Painting | Upon request | |
| Crane boom main parameters | ||
| Crane boom | Choose to install SHIMEI 16tons telescopic 5 sections knuckle crane boom | |
| Max lifting height | 23.3m | |
| Max Working radius | 21.7m | |
| The color of the whole truck is upon request. Choose to install double rear ladders. | ||
