HOT SALE! DONGFENG 4*2 LHD 4cbm asphalt spreading tanker vehicle for sale, 2021s Euro 6 new model 3tons asphalt truck
HOT SALE! DONGFENG brand 4*2 LHD 4cbm asphalt spreading tanker vehicle for sale, 2021s Euro 6 new model 3tons asphalt spreading truck for sale
DONGFENG 4CBM bitumen spreading tanker truck adopts EQ1075SJ3CDF, 3308mm wheelbase, 5 speed gearbox, 7.00R16 rail tires, CY4BK461 chaochai 129hp diesel engine/YCY24140-60 yuchai 140hp diesel engine/ D20TCIF1 yunnei 126hp diesel engine, Euro Ⅵ emission standard.
The devices of intelligent type dongfeng brand 4cbm 3tons asphalt distributing vehicle manufactured by Chengli Special Automobile Co., Ltd. as below.
1, the asphalt pump adopts high quality QGB680 (high viscosity asphalt pump, 680L/min).
2, hydraulic system: the model of hydraulic motor for asphalt pump: 05-110-BD31; hydraulic pump model: CBQ550-L; Proportional valve (Taiwan EFBG-03-160-HF); Automatic reversing valve and overflow valve, radiator adopts Risheng brand.
3, control way: Intelligent touch screen computer control in the cab; control system: (Siemens, Germany), 30 intelligent asphalt spraying nozzles (one controls one).
4, Heating method: Burner (Italy imported Riello brand burner model G10)+ Automatic heating of heat transfer oil
5, gasoline generator unit: 6KW
6, asphalt distributing width: 4m; spreading amount: 0.25-2.5L/㎡
7, Distributing medium: emulsified asphalt, hot asphalt, SBS hot asphalt
If you're interested in our asphalt tanker truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
More pictures of dongfeng 4cbm asphalt spreading tanker truck manufactured by Chengli Special Automobile Co., Ltd. as below.
Customized new dongfeng 4*2 LHD diesel bitumen tanker truck for sale
HOT SALE! DONGFEENG EURO 6 diesel asphalt tanker truck for sale
Main technical parameters of dongfeng 4cbm intelligent asphalt tanker truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Main technical parameters | |||
| Product name | CLW5070GLQD6 asphalt spreading tanker truck for sale | ||
| Total mass(Kg) | 7360 | Tanker volume(m3) | 4 |
| Rated mass(Kg) | 2080 | Overall dimension(L*W*H)(mm) | 6300×2080×2400 |
| Curb mass(Kg) | 5150 | Driver cab seated person | 2 |
| Approach/departure angle(°) | 27.7/13,27.7/14 | Front/rear suspension (mm) | 1055/1937 |
| Axle no. | 2 | wheelbase(mm) | 3308 |
| Axle load(Kg) | 2640/4720 | Max speed(Km/h) | 110 |
| Chassis main parameters | |||
| Truck chassis | EQ1075SJ3CDF | Manufacturer: | dongfeng |
| Approach/departure angle(°) | 27.7/15 | Tire specification | 7.00R16*6 |
| Steel spring | 6/6+5,3/3+3 | Front tread(mm) | 1525 |
| Fuel type | Diesel | Rear tread(mm) | 1498 |
| Emission standard | Euro Ⅵ | ||
| Engine model | Manufacturer | displacement(ml) | power(Kw) |
|
D20TCIF1 YCY24140-60 CY4BK461 |
YUNNEI YUCHAI CHAOCHAI |
1999 2360 3707 |
93 103 95 |
