SINO TRUK HOWO 6*4 RHD 371hp diesel 16CBM 14T asphalt tanker truck for sale, bitumen spreading tanker truck for sale
SINO TRUK HOWO 6*4 RHD 371hp diesel 16CBM 14T asphalt tanker truck for sale, bitumen spreading tanker truck for sale
Customized SINO TRUK HOWO 6*4 RHD 16CBM asphalt spreading truck adopts SINO TRUK HOWO HW76 luxurious one row and a half driver cab, HW19710 10 speed gearbox, HW70 PTO, ST16 16T rear axle, 12.00R20 rail tires, ZF8198 steering wheel,etc.
The details of standard type 16cbm asphalt tanker truck manufactured by Chengli Special Automobile Co., Ltd. as below.
The devices of dongfeng 153 10cbm asphalt tanker truck manufactured by Chengli Special Automobile Co., Ltd. is as below.
1, the asphalt pump adopts high quality QGB950 (high viscosity asphalt pump, 950L/min).
2, hydraulic system: Proportional valve (Taiwan EFBG-03-160-HF); Automatic reversing valve and overflow valve; radiator adopts Risheng brand; the model of hydraulic motor for asphalt pump: 05-110-BD31; hydraulic pump model: CBQ550-L or Power take off after engine GPC4-50R.
3, control way: Intelligent touch screen computer control at the driver cab; control system: (Siemens, Germany), 36 sets intelligent asphalt spraying nozzles (one controls one).
4, Heating method: Burner (Italy imported Riello brand burner model G20) + Automatic heating of heat transfer oil
5, gasoline generator unit: 6KW
6, spreading amount: 0.25-4L/㎡;
7, asphalt distributing width: 4.5m, 48 sets spraying nozzles for 6m spreading width is selective (10000RMB additional).
8, Distributing medium: emulsified asphalt, hot asphalt, SBS hot asphalt, etc.
Main technical parameters of SINO TRUK HOWO 6*4 LHD 336hp diesel asphalt spreading tanker truck is as below.
| Main technical parameters | |||
| Product name | CLW5250GLQZ asphalt tanker truck for sale | ||
| Total mass(Kg) | 25000 | Tanker volume(m3) | 16 |
| Rated mass(Kg) | 9000 | Overall dimension(L*W*H)(mm) | 10100×2500×3563,3420 |
| Curb mass(Kg) | 15870 | Driver cab seated person | ×× |
| Approach/departure angle(°) | 16/10 | Front/rear tread(mm) | 1500/2650,1500/2625 |
| Axle nos. | 3 | wheelbase(mm) | 4600+1350,4575+1400 |
| Axle load(Kg) | 7000/18000(tri axles) | Max speed(Km/h) | 90 |
| Truck chassis main parameters | |||
| Truck chassis modle | ZZ1257 | Manufacturer | SINO TRUK HOWO COMPANY |
| Approach/departure angle(°) | 16/18 | Tire specification | 295/80R22.5 |
| Steel spring | 10/12, | Front tread(mm) | 2022 |
| Fuel type | Diesel | Rear tread(mm) | 1830/1830 |
| Emission standard | Euro Ⅲ | ||
| Engine model | Manufacturer | displacement(ml) | power(Kw) |
|
WD615.47 WD615.69 |
Sino truk Sino truk |
9726 9726 |
273 247 |
More pictures of SINO TRUK HOWO 6*4 RHD 371hp diesel 16cbm 14tons asphalt spreading tanker truck manufactured by Chengli Special Automobile Co., Ltd. as below.
If you're interested in our asphalt tanker truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
asphalt distributor is a kind of pavement construction machinery; it is a highway, urban road, airport and port construction of major equipment.It can be used to transport and makes liquid asphalt (including hot asphalt, emulsified asphalt and residue) . The bitumen distributor truck are consisted with truck chassis, insulated asphalt tank, heater, hydraulic system, conducting oil pipeline, asphalt pump, spray nozzle, etc. The tank volume is from 3m3 to 18m3. The spray nozzle quantity is from 30 to 48.
The emulsified asphalt distributor truck is also called asphalt paver, asphalt sprayer truck, bitumen sprayer truck, asphalt distributor truck, asphalt bitumen tank truck, road sealer truck, asphalt truck, etc. The liquid bitumen sprayer truck is mainly used to transport asphalt and distribut it for sealing the road.
The asphalt distributor trucks manufactured by Chengli Special Automobile Co., Ltd. adopt advanced technology and foreign imported parts. It has more advantages than other asphalt suppliers.Our asphalt sparyer truck for sale adopt special chassis and Italy imported burner. It has many advantages.
