HOT SALE! SHACMAN 4*2 130hp diesel refrigerated truck, customized refrigerated truck for vegetables and fruits for sale
HOT SALE! SHACMAN 4*2 LHD 130hp diesel refrigerated truck, customized refrigerated truck for vegetables and fruits for sale
overall dimension(L*W*H): 5995×2260×3155(mm)
refrigerate van box dimension(L*W*H): 4080x2100×2000(mm)
loading capacity: 2tons-3tons
Truck chassis devices as below.
wheelbase: 3300mm
engine model: WP2.3NQ130E61 130hp diesel engine
gearbox: :6 speed manual gearbox,
tire specification:7.00R16
other: 2050mm wider driver cab with air conditioner, 2.5tons front axle/ 5tons rear axle, etc.
Exterior and interior with FRP(Fiber Reinforced Plastic), and the middle with PU slices with vacuum negative pressure one-formed casting as the insulation layer, approved the related Ministry of Health of food grade requirements, etc. just like sandwich structure. Baseboard adopts anti-skipping diamond board, which assuring the insulation ability and the compact resistance of the baseboard. double rear door opened. Choose high quality China made self-powered frozen refrigerating reefer of the model of T-800M, the lowest temperature is up to -18℃. And the reefer can be adjusted at the driver cab.
The cold room van body is install stainless steel material pharmaceutical products ventilation slots and temperature and humidity recorder with printing function and GPS (Global Positioning System).
Main technical parameters of SHACMAN brand 4*2 LHD 130hp diesel refrigerated truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Items | Descriptions | Specifications and Types |
| General | Truck Name | SHACMAN brand 4*2 LHD Refrigerator truck for sale |
| Drive Type | 4*2 LHD | |
| Fact Loading Weight(kg) | 2ons-3tons | |
| Total mass(kgs) | 4495 | |
| Curb Weight (kg) | 3200 | |
| Overall Dimensions (mm) | 5995×2260×3155(mm) | |
| Engine | Engine Model | WP2.3NQ130E61 |
| Engine Brand | Weichai | |
| Fuel Type | Diesel | |
| Power | 130hp | |
| Emission Standard | Euro Ⅵ | |
| Chassis | Chassis model | YTQ1041KH331 |
| Chassis Brand | Shacman | |
| Tire Specification | 7.00R16 | |
| Wheelbase (mm) | 3300mm | |
| Axle No. | 2 | |
| Steering Wheel | Left hand drive | |
| Gear Box | 6speed forward with 1 reverse, manual | |
| Air-conditioner | No | |
| Cold Room | Box inner dimension(mm) | 4080x2100×2000 |
| Box Side | Exterior and interior with FRP(Fiber Reinforced Plastic), and the middle with 80mm PU slices with vacuum negative pressure one-formed casting as the insulation layer, approved the related Ministry of Health of food grade requirements, etc. just like sandwich structure. | |
| Box Floor | Baseboard adopts aluminum alloy anti-skipping diamond board, which assuring the insulation ability and the compact resistance of the baseboard. | |
| Doors |
Frame of standard rear double doors adopts the stainless steel structure frame with light mass and perfect corrosive resistance, etc. The door edgings frames are sealed with the imported high quality epdm rubber, making sure the van insulation stability. Aluminum alloy Door edgings, Stainless steel material Door locks and accessories |
|
| Refrigerator Unit | Refrigeration unit | Choose high quality China-made or USA CARRIER/THERMO KING vehicle-powered refrigerated unit, the temperature can be adjusted at 15 degree below zero to zero degree. And the cooling unit can be adjusted at the driver cab. |
| Refrigerated temperature | -15° to 0° |
If you're interested in our refrigerated truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
More pictures of SHACMAN brand 4*2 LHD 130hp diesel refrigerated truck manufactured by Chengli Special Automobile Co., Ltd. as below.
