Customized HOWO 6*4 RHD 336hp diesel asphalt tanker distributing vehicle for sale, Best price bitumen spreading truck
The bitumen distribution truck for sale are consisted with truck chassis, insulated asphalt tank, heater, hydraulic system, conducting oil pipeline, asphalt pump, spray nozzle, etc. The tank volume is from 3m3 to 18m3. The spray nozzle quantity is from 30 to 48 nos.
The liquid bitumen sprayer truck is mainly used to transport asphalt and distribut it for sealing the road.
Our asphalt distributor dopt advanced technology and foreign imported parts. It has more advantages than other asphalt suppliers.
Our asphalt sparyer truck for sale adopt special chassis and Italy imported burner. It has many advantages.
The asphalt tank distributing vehicle is a kind intelligent automated high-tech special vehicle for distributing different kinds of asphalts such as emulsified asphalt, diluted asphalt, hot asphalt, High viscosity modified asphalt, etc. It is used for distributing the permeable oil waterproof layer on the bottom of asphalt pavement of high grade highways. The asphalt distributing vehicle is made up of truck chassis, asphalt tank body, asphalt pump delivering and spraying system, thermal oil heating system, hydraulic system, combustion system, control system, Pneumatic system, operation platform, etc.
If you're interested in our SINO TRUK HOWO 6*4 RHD
Customized SINO TRUK HOWO 6*4 RHD 16CBM asphalt spreading truck adopts SINO TRUK HOWO HW76 luxurious one row and a half driver cab, HW19710 10 speed gearbox, HW70 PTO, ST16 16T rear axle, 12.00R20 rail tires, ZF8198 steering wheel,etc.
The details of standard type 16cbm asphalt tanker truck manufactured by Chengli Special Automobile Co., Ltd. as below.
1, the asphalt pump adopts high quality QGB950 (high viscosity asphalt pump, 950L/min).
2, hydraulic system: manual Proportional valve; the model of hydraulic motor for asphalt pump: 05-130-BD31; hydraulic pump model: CBQ550-L
3, control way: controlled the control box at the rear working platform, 36 sets intelligent asphalt spraying nozzles (one controls one).
4, Heating method: Burner (Italy imported Riello brand burner model G20) + Automatic heating of heat transfer oil.
5, asphalt distributing width: 4.5m, 48 sets spraying nozzles for 6m spreading width is selective (10000RMB additional).
6, spreading amount: 0.25-3.5L/㎡;
7, gasoline generator unit: 6KW
8, Distributing medium: emulsified asphalt, hot asphalt, SBS hot asphalt, etc.
Website: www.trucksinchina.com
Whatsapp/Wechat/Mob.: 0086 13329899995
Email: clwtrucks2020@gmail.com
More pictures of SINO TRUK HOWO 6*4 LHD 336Hp diesel asphalt tanker truck as below.
Main technical parameters of SINO TRUK HOWO 6*4 LHD 336hp diesel asphalt spreading tanker truck is as below.
| Main technical parameters | |||
| Product name | CLW5250GLQZ asphalt tanker truck for sale | ||
| Total mass(Kg) | 25000 | Tanker volume(m3) | 16 |
| Rated mass(Kg) | 9000 | Overall dimension(L*W*H)(mm) | 10100×2500×3563,3420 |
| Curb mass(Kg) | 15870 | Driver cab seated person | ×× |
| Approach/departure angle(°) | 16/10 | Front/rear tread(mm) | 1500/2650,1500/2625 |
| Axle nos. | 3 | wheelbase(mm) | 4600+1350,4575+1400 |
| Axle load(Kg) | 7000/18000(tri axles) | Max speed(Km/h) | 90 |
| Truck chassis main parameters | |||
| Truck chassis modle | ZZ1257 | Manufacturer | SINO TRUK HOWO COMPANY |
| Approach/departure angle(°) | 16/18 | Tire specification | 295/80R22.5 |
| Steel spring | 10/12, | Front tread(mm) | 2022 |
| Fuel type | Diesel | Rear tread(mm) | 1830/1830 |
| Emission standard | Euro Ⅲ | ||
| Engine model | Manufacturer | displacement(ml) | power(Kw) |
|
WD615.47 WD615.69 |
Sino truk Sino truk |
9726 9726 |
273 247 |
