HOT SALE! new manufactured Tangjun 4*2 LHD 8T mobile truck crane, smaller 8tons mobile truck mounted crane for sale
HOT SALE! new manufactured Tangjun 4*2 LHD 8T mobile truck crane, smaller 8tons mobile truck mounted crane for sale
Mobile crane is also called truck crane, a kind of crane mounted on general truck chassis or special purpose truck chassis. The driving cabin and lifting operation cab are setted separately. The advantage of this kind of mobile truck crane is flexibility and moving quickly; while the weakness is work must be outrigger, cannot load driving and at the same time cannot work on the a soft or muddy field. And this kind of mobile truck crane is widely used for Engineering Constructions, such as Roads, bridges, buildings, emergency services, etc. The general engineering team, the construction industry and the electric power installment department, all needs the automobile crane.
Today, we will introduce Tangjun 4*2 LHD 8T mobile truck crane as below.
Overall dimension(L*W*H): 9600*2110*3000(mm)
Crane boom: 6.5m 5 sections out driving rope(with Retracting Rope)
Full Crane boom length: 28m
Engine power: weichai 130hp
Gearbox: wanliyang
Main/auxiliary hoist: 10T/5T
More pictures of tangjun 4*2 LHD 8tons mobile crane truck as below.
Main technical parameters of TANGJUN 4*2 LHD 8T mobile crane truck manufactured by Chengli Special Automobile Co., Ltd. is as below.
| Main technical parameters of | |||
| Total mass | 9100kg | Total mass(kg) | 8000 |
| Engine model | WP2.3NQ130E61 weichai 130hp | Main/auxiliary hoist | 10T/5T |
| Displacement/ power (ml/kw) | 2289/96 | Crane boom | 6.5m 5 sections out driving rope(with Retracting Rope) |
| Gearbox | Wanliyang | Full crane boom length (m) | 28 |
| Overall dimension(L*W*H)(mm) | 9600*2110*3000 | Big boom dimension(mm) | 450*300 |
| Wheelbase | 3360mm | Back displacement top | Standard |
| Tires pec | 750R16 rail tires | Slewing bearing | external gear |
| Front/rear axle(kgs) | 3300/5800 | Slewing mechanism | 360°Arbitrary rotation |
| Outrigger Longitudinal/transverse span(mm) | 4200/4800 | Beam | new torque-fighting beam |
| Steering type | Hydraulic steering | Power pump | Single pump |
| Braking | Air cut braking | Operation room | Advanced operation room |
| Others: Fully covered floor, double-sided operation, negative angle, electronic throttle | |||
| Chosen part: Double Legs, motor, computer, weighing apparatus, camera, rotating basket, air conditioning, level | |||
| Main technical parameters | |||
| Product name | Tangjun 4*2 LHD 8T mobile truck crane | ||
| Total mass(Kg) | 9100 | Overall dimension(L*W*H)(mm) | 9600×2110,2150×3000,3110 |
| Curb mass (Kg) | 8905 | Approach/departure ang;e(°) | 13/9 |
| Driver seated person | 3 | Front/rear suspension(mm) | 1160/2180 |
| Axle no. | 2 | wheelbase(mm) | 3360 |
| Axle load(Kg) | 3300/5800 | Max speed(Km/h) | 75 |
| Chassis | |||
| Truck chassis model | ZB5090JQZJPD6L | Truck chassis | Truck crane truck chassis |
| Overall dimension(L*W*H)(mm) | 5990×2100×2300 | Tire no/ | 6 |
| Approach/departure angle(°) | 13/15 | Tire specification | 7.50R16LT 16PR |
| Steel spring | 6/9+5 | Front tread(mm) | 1700 |
| Fuel type | Diesel | Rear tread(mm) | 1650 |
| Emission standard | Euro Ⅵ | ||
| Engine model | Manufacturer | displacement(ml) | power(Kw) |
| WP2.3NQ130E61 | Weichai | 2289 | 96 |
