HOT SALE! customized RHD 3T-5T garbage dump truck for domestic wastes transportation, GOOD PRICE! 4T dump tipper truck
HOT SALE! customized RHD 3T-5T garbage dump truck for domestic wastes transportation, GOOD PRICE! 4T dump tipper truck for sale
Customized CLW brand RHD 90hp diesel garbage dump tipper truck for sale,
HOT SALE! RHD diesel dump garbage truck for sale
Factory sale dump tipper truck hydraulic cover for sale
If you're interested in our dump garbage truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
main technical parameters of CLW brand 3T-5T dump garbage truck manfuactured by Chengli Special Automobile Co., Ltd. is as below.
| Items | Descriptions | Specifications and Types |
| General | Truck Name | CLW brand 4*2 RHD 4tons dump tipper truck for sale |
| Drive Type | 4*2 RHD | |
| Total mass(kg) | 6010 | |
| Fact Loading Capacity(kg) | 3000-5000kgs | |
| Curb Weight (kg) | 3500 | |
| Overall Dimensions L*W*H(mm) | 5850*2000*2380 | |
| Engine | Engine Model | CY4100Q |
| Engine Brand | Chaochai | |
| Fuel Type | Diesel | |
| Power | 60kw/82HP | |
| Emission Standard | Euro III | |
| Displacement(ml) | 3707 | |
| Engine Type | 4 cylinder Vertical, in-line, water-cooled, 4-stroke | |
| Chassis | Chassis Brand | Dongfeng EQ1060 |
| Front/Rear Axle Load(KG) | 1700/2565 | |
| Tire No. | 6 | |
| Tire Specification | 7.00R16 | |
| Wheelbase (mm) | 3300 | |
| Axle No. | 2 | |
| Gear Box | 5 speed forward with 1 reverse, manual | |
| Brake | Air brake | |
| Steering Wheel | Right Hand Drive with power-assisted, | |
| Tipping system | Box inner dimension(mm) | 3760*1880*600 |
| Box material | Carbon steel, side sheet: 3mm thickness, bottom 4mm thickness | |
| Hydraulic cylinder position | Double cylinders at the center of the truck bottom | |
| Discharge type | Rear tipping | |
| Remark | Clients choose to install environmental protection hydraulically cover | |
CLW brand 4*2 RHD dump truck, adopts single row reserved driver cab, chaochai 95hp diesel engine, 3300mm wheelbase, 5 speed transmission, 1058 front/rear bridge, 7.00R15 rail tires, etc.
And the overall dimension of the CLW mini dump truck is 5850*2000*23800(mm), cargo body dimension is 3760*1880*600 adopting high quality GB carbon steel, etc.
Dump truck is also called tipper, dump tipping vehicle, sand and stone transporting vehicle, etc. Dump truck is mainly used for transporting loose material (such as sand, gravel, or dirt) for construction. A typical dump truck is equipped with an open-box bed, which is hinged at the rear and equipped with hydraulic pistons to lift the front, allowing the material in the bed to be deposited dumped on the ground behind the truck at the site of delivery.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of dump truck in China since 2004s. And we can offer dongfeng dump truck, HOWO dump truck, ISUZU tipper truck, FAW dump tipper, North Benz dump truck, tipper trailer, etc. 4*2 dump truck, 4*4 dump truck, 6*4 tipper truck, 8*4 dump truck, etc. More information, please feel free to contact with Ms. Anita Deng.
