Customized FOTON AUMARK 4*2 LHD 240hp diesel 6.7m day old chick transported truck for sale， 60000 day old birds truck
Customized FOTON AUMARK 4*2 LHD 240hp diesel 6.7m length day old chick transported truck for sale 60,000 day old birds
transported truck for sale
Customized FOTON AUMARK 4*2 LHD 240hp diesel day old chick transported truck for sale, adopts FOTON AUMARK LHD 2200mm one row and a half driver cab with air- conditioner+power steering, 5150mm wheelbase, YC6A240-33 176KW/240hp Euro Ⅱ diesel engine, 8 speed manual gearbox, 5.5tons front axle/10tons rear axle, 11R22.5 rail tires, air cut braking, etc.
The technical parameters of upper part for FOTON AUMARK LHD day old chicks transported truck as below
The cold van body dimension of FOTON AUMARK LHD 6.7m length day old chicks transported carrier is 6670×2300×2400 (mm). The interior and exterior of the van box body with fiber reinforced plastics(FRP), and the middle insulation layers of 80mm thickness PU foam. There are sliding windows and waterproof blind-windows. The air will be from the van body floor ventilation.
| Product name | Foton Aumark 4*2 LHD day old chick transported truck | ||
| Overall dimension(L*W*H)(mm) | 9100×2470×3760 | Chick van box dimension(L*W*H)mm | 6670×2300×2400 (mm). |
| Drive type | 4*2 LHD | Total mass | 15795 |
| Gearbox | 8 speed transmission, manual | Tyre specification | 11R22.5 rail tyres *6+1 |
| Power steering | Yes | Exhaust braking | Yes |
| Air cut braking | Yes | Driver cab | Foton Aumark LHD 2200mm one row and a half driver cab with air conditioner+power steering |
| Engine | YC6A240-33 | Emission standard | Euro Ⅱ |
| Rater power | 176KW/240hp | Displacement (ml) | 7000 |
Main technical parameters of day old chick van body
| Performance and consumption | |||
| Heating system | Watering system | Without, client choose to install | |
| Cooling system | One refrigerated reefer | China made high quality vehicle-powered refrigerated reefer( the lowest temperature inside the cold room box up to -10℃, adjusted at the driver cab) | |
| Ventilation system | Air duct installed on the floor for air flow | three line as the pictures show | |
| Cold air ducts on the two sides of the van body | two cold air ducts for the refrigerated reefer | ||
| Blind windows | 5 sets of blind windows for the left and right van sides (as the pictures show); two bigger water-proof blind window at the front van plate. Blind Windows: 5*2+2=12 |
||
| electronic ventilator fans | 1, 4 sets of electronic ventilator fans with sliding doors for the rear plate door; 5*2 sets of electronic ventilator fans for van top Electronic fans: 4+5*2=14 |
||
| Sky-window | Top mounted sky windows*4 Sky-windows: 4*1=2 | ||
| Dimension | |||
| Chick van box body | Length | 6670mm | |
| Width | 2300mm | ||
| Height | 2400mm | ||
| Refrigerated van box | Exterior and interior with FRP( fiber reinforced plastic), and the middle with 80mm PU slices; Aluminum-patterned baseplate; |
||
If you're interested in our day old chick transported truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
More pictures of FOTON 4*2 LHD 240hp diesel day old birds transported truck as below.
e baby chick trucks manufactured by Chengli Special Automobile Co., Ltd. adopts high quality Fiberglass Reinforced Plastic (FRP) for exterior and interior layer, and the middle insulation layer with 80mm PU foam sheets.
And we can customized the day old chick trucks, installed with cooling system, heating system, Ventilation system, windows and fans, etc. More information, please feel free to contact with Ms. Anita.
Truck for transported day old chick is a kind of special insulation van truck for transporting day old chickens and eggs, etc. It is suitable for large chick farms, etc.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of van truck in China. With many years’ development, Chengli Special Automobile Co., Ltd. could supply refrigerated truck, insualtion body van box, cargo van truck, baby chick transported truck, etc. And our CLW brand van truck have been exported to many countries all over the world. More information, please feel free to contact with Ms. Anita.
