Mobile crane is also called truck crane, a kind of crane mounted on general truck chassis or special purpose truck chassis. The driving cabin and lifting operation cab are setted separately. The advantage of this kind of mobile truck crane is flexibility and moving quickly; while the weakness is work must be outrigger, cannot load driving and at the same time cannot work on the a soft or muddy field. And this kind of mobile truck crane is widely used for Engineering Constructions, such as Roads, bridges, buildings, emergency services, etc. The general engineering team, the construction industry and the electric power installment department, all needs the automobile crane.
the technical advantages of CLW brand truck crane as below.
1. Customized cab of truck crane
2. Differentiated design, wide use scenarios
3. Multi-task power platform is selected, and the application area is wide
4. Single-board arm head, compact arm circumference, stilt-type counterweight box, work more convenient
5. The intelligent lifting operation room can effectively reduce the driving height and improve the passing rate and stability of the whole machine.
If you're interested in our crane truck, please send email to truck0011@163.com; or talk to Anita by Whatsapp/Wechat/Mob.: 0086 13329899995
Website: www.trucksinchina.com
Overall dimension(L*W*H): 10800*2370*3420
crane boom: 9m 5 sections veneer U type boom
full crane boom length: 39.5m
engine model: weichai 190hp
gearbox: fastgear
wheelbase: 4500mm
Tire specification: 1000R20 rail tires
Main/auxiliary hoist: 16T/16T
More pictures of FOTON 16T mobile crane truck manufactured by Chengli Special Automobile Co., Ltd. is as below.
Main technical parameters of FOTON 4*2 LHD 16T mobile crane truck is as below.
| Foton 12T mobile crane truck for sale | |||
| Total mass | 18000KGS | Max lifting mass(kg) | 16000 |
| Engine model |
WP4.1NQ190E61 Weichai 190hp |
Main/auxiliary hoist | 19T/19T |
| Displacement/ power (ml/kw) | 4088/140 | Crane boom | 9m 5 sections veneer U type boom |
| Gearbox | fastgear | Full crane boom length (m) | 39.5 |
| Overall dimension(L*W*H)(mm) | 10800*2370*3420 | Big boom dimension(mm) | 600*500 |
| Wheelbase | 4500mm | Back displacement top | Standard |
| Tires pec | 900R20 rail tires | Slewing bearing | External gear |
| Front/rear axle(kgs) | 6000/12000 | Slewing mechanism | 360°Arbitrary rotation |
| Outrigger Longitudinal/transverse span(mm) | 5100/7100 | Beam | new torque-fighting van beam |
| Steering type | Hydraulic steering | Power pump | Triple-pump |
| Braking | Air cut braking | Operation room | Advanced operation room |
|
Others: 18.5T without payload, Fabricated process, double outriggers, extended boom of 15m length with the loading capacity of 16T, Truck-mounted oil circuit,
|
|||
| Chosen part: 17KW electronic motor, computer, weighing apparatus, camera, rotating basket, air conditioning, level | |||
Main technical parameters of FOTON 16T mobile crane truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Main technical parameters | |||
| Product name | BJ5184JQZHPFG-01 FOTON 16T mobile crane truck for sale | ||
| Total mass(Kg) | 18000 | Overall dimension(L*W*H) | 10800*2370*3420 |
| Curb mass(Kg) | 17805 | Driver cab seated person | 3 |
| Approach/departure angle(°) | 17/10 | Front/rear suspension(mm) | 1260/2860 |
| Axle load | 2 | wheelbase(mm) | 4500 |
| Axle load(Kg) | 6000/12000 | Max speed(Km/h) | 85 |
| Chassis main parameters | |||
| Truck chassis | BJ1184VKPFG-01 | Manufacturer | FOTON |
| Approach/departure angle (°) | 21/26 | Tire specification | 10.00R20 18PR*6 |
| Steel spring | 10/12+9 | Front tread(mm) | 1755 |
| Fuel type | Diesel | Rear tread(mm) | 1740,1724 |
| Emission standard | Euro Ⅵ | ||
| Engine model | Manufacturer | displacement(ml) | power(Kw) |
| WP4.1NQ190E61 | Weichai | 4088 | 140 |
