New FOTON AUMARK S 4T-5T refrigerated truck for sale,FOTON 5m length reefer van truck for bag milk transportation
New FOTON AUMARK S 4T-5T refrigerated truck for sale,FOTON 5m length reefer van truck for bag milk transportation
HOT SALE!FFOTON AUMARK 4*2 LHD 4T-5T refrigerated truck for bag milk transportation
Main technical parameters of FOTON AUMARK 4*2 LHD refrigerated truck is as below.
| Items | Descriptions | Specifications and Types |
| General | Truck Name | FOTON AUMARK 4*2 LHD diesel refrigerated truck for sale |
| Drive Type | 4*2 LHD | |
| Total mass(kgs) | 8275 | |
| Curb mass(kgs) | 4000 | |
| Rated mass(kgs) | 4080 | |
| Overall Dimensions (mm) | 7015×2300×3420 (mm) | |
| Driver cab | FOTON AUMARK 2060mm single row driver cab with 3 seats(driver cab included) | |
| Engine | Engine Model | ISF3.8s3141 |
| Engine Brand | FOTON CUMMINS | |
| Fuel Type | Diesel | |
| Rated power(KW/hp) | 104KW/141hp | |
| Cylinders nos. | 4 cylinders | |
| Emission Standard | Euro Ⅲ | |
| Capacity (cc) | 3760 | |
| Chassis | Chassis Brand | FOTON |
| Tire Specification | 8.25R20 (RADIAL) | |
| Wheelbase (mm) | 3800 | |
| Axle No. | 2 | |
| Front/Rear axle | 3.6ton front axle/6.3ton rear axle | |
| Steering Wheel | Left hand drive | |
| Gear Box | 6S558 ZF 7 speed lever with six speed forward and one reverse, manual gearbox | |
| Brake | Air brake | |
| Steel spring | 9/8+6 | |
| Electric | 24V | |
| Air-conditioner | No, choose to install air conditioner | |
| Cold Room | Box inner dimension(mm) | 5000×2200×2300 (mm) |
| Box Side | Exterior and interior with FRP(fiber Reinforced Plastic), and the middle with 80mm PU slices with vacuum negative pressure one-formed casting as the insulation layer, approved the related Ministry of Health of food grade requirements, etc. just like sandwich structure. | |
| Box Floor | Baseboard adopts aluminum alloy anti-skipping diamond board, which assuring the insulation ability and the compact resistance of the baseboard. | |
| Doors |
Frame of standard rear double doors adopts the stainless steel structure frame with light mass and perfect corrosive resistance, etc. The door edgings frames are sealed with the imported high quality epdm rubber, making sure the van insulation stability. Door edgings, door locks and accessories use stainless steel materials. |
|
| Refrigerator Unit | Refrigeration unit |
Choose high quality USA Carrier brand vehicle-powered reefer unit (reefer unit model: C-500), the lowest temperature up to -10℃, adjusted at the driver cab).
|
FOTON AUMARK 4*2 LHD refrigerated truck customized for bag milk transportation adopts FOTON AUMARK S series 2060mm single row driver cab, 3800mm wheelbase, F3.8s3141 Cummins 104KW/141hp Euro Ⅲ diesel engine, 3.6tons front axle/6.5T rear axle, 8.25R20 rail tires*6+1, 6S558 ZF 7 speed lever with six speed forward and one reverse manual gearbox, air cut braking, 24V electric, 9/8+6 steel spring, etc.
The overall dimension (L*W*H) of the FOTON AUMARK 4*2 LHD refrigerated truck is 7015×2300×3420(mm); while the cold van box dimension(L*W*H): 5000×2200×2300(mm). Clients choose to install High quality USA Carrier brand vehicle-powered reefer unit (reefer unit model: C-500), the lowest temperature up to -10 ℃, adjusted at the driver cab).
Exterior and interior with FRP(Fiber Reinforced Plastic), and the middle with PU slices with vacuum negative pressure one-formed casting as the insulation layer, approved the related Ministry of Health of food grade requirements, etc. just like sandwich structure. Baseboard adopts anti-skipping diamond board, which assuring the insulation ability and the compact resistance of the baseboard. double rear door opened.
If you're interested in our refrigerated truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: 0086 13329899995.
Website: www.trucksinchina.com
More pictures of FOTON AUMARK 4*2 LHD 5m length refrigerated turck for bag milk transportation as below.
HOT SALE! foton aumark S 5m refrigerated truck for sale
High quality and best price FOTON AUMARK 4T-5T cold van truck for sale
Chengli Special Automobile Co., Ltd manufactures refrigerator trucks since 2004s in China. With so many years’ experience in manufacturing, we Chengli Special Automobile Co. Ltd could manufacture and sell vaccine delivery vehicle, meat hook refrigerated truck, fruit and vegetables refrigerated truck, milk food transport refrigerator truck, insulation van truck, van refrigerated truck, freezer minibus, small refrigerated truck, medium freezer van truck, big refrigerated truck, refrigerator semi-trailer, freezer refrigerated vehicles, dongfeng brand cold room truck, ISUZU brand refrigerated truck, FAW refrigerated truck, FOTON refrigerated truck, Chang’an freezer van truck, Yuejin refrigerated truck, JMC refrigerated truck, CMAC refrigerator truck, Aoling refrigerated truck, the smallest refrigerated truck, etc. More information, please feel free to contact with Ms. Anita.
