Exported Indonesia Boiler Economizer Green Painted Double H Fin Tuber Carbon Steel
Specification:
1.Economizer is a heat exchanger device that captures the "lost or waste heat" from the boiler's hot stack gas.
3.Our enconomizer is squeezing by high frequency welding method and the technology of steel strip according to certain structure automatically, continuous spiral welding outside the light tube wall, and then the other reserved part light tube bending, combination according to the requirement. As a result, the diameter and length under the same conditions, it has larger heat transfer area.
Introduction:
1.In boilers, Economical low installation costs better performance boiler economizer for CFB boiler are heat exchange devices that heat fluids, usually water, up to but not normally beyond theboiling point of that fluid.
Parameter:
| Name | Economical low installation costs better performance boiler economizer for CFB boiler |
| specifications of finned tube | unit(mm) |
| Bare pipe(od) | 25-165 |
| bare pipe(thick) | 2-8 |
| finned thicks | 0.6-3.0 |
| finned height | 5-30 |
| finned tube thread pitch | 5-30 |
| finned tube length | </=12000 |
| Remark | 1.Other specifications outside the table should be proposed, it is negotiable. 2.Generally speaking, the height of the fin <=1/2d 3 The spiral finned tubes produced by our company are manufactured according to the principle:JB/T6512-92 DG1020-97 |
Accessory:
1.The boiler economizer acts as a waste heat recovery device, ensuring that this heat does not go unused.
2.Instead, the heat is used to essentially preheat the water, so that less heat is required to bring the water to a temperature high enough to make steam
3.Boiler parts Heat exchanger H Fin tube economizer used in utility boilers, industrial boilers, marine power, such as the tail of heat exchanger components.
Performance characteristics :
1. Excellent anti-wear performance
2. Less fouling
3. Compact space
4. Welded Joints less
5. Stability
Other products:
Our main products including CFB boiler, coal fired boiler and boiler parts such as tubular air pre-heater, rotary air pre-heater, super heater, re-heater, header, membrane water wall and economizer.
