HOWO 10 Wheels 20000L Water Bowser Truck 18 tons 20 tons Color Customized

Price Negotiable
Price: Could be negotiated
MOQ: 1 unit
Delivery Time: 30-35 days after receiving the deposit
Product Description

Sinotruk HOWO 10 wheels 18000L 20000L Water Transport Tank Truck 18tons 20tons Water Tanker Truck



Product features:



1, Sinotruk WD615.62, WD615.87, WD615.69, WD615.47, 266hp, 290hp, 336hp,371hp are optional.

     Euro-2 emmission standard. Mechanical manual Injector.
2, Volume of tank: 16000L-24000L, 16M3-24M3, 16cbm-24cbm

3, Low oil consumption with good economic.

4, Pump: Chinese famous brand pump with PTO

5, Self suction, self discharge function, front flushes sprinkles, side spurts, post positioned work table.

6, High-pressured Sprinkler, spraying of water to be possible to adjust columnar and the fog shape.

7, Optional fire pump and fire-fighting accessories.

8, Especially suitable for the municipal administration environmental sanitation department, the large-scale industry and mining enterprise.

9,BV ISO9001; CCC approved, accept customes' OEM customized.

10, 4x2 truck chasiss, 6 wheeler; 6x4 truck chasiss, 10 wheeler; 8x4 truck chassis,  12 wheeler



water sprinkler tanker features:



1, Applied carbon steel sheet Q235-A; Stainless steel; Aluminium alloy for loading the drinking water.

2, Applied the famous pump.

3,The main parts implements automatic welding.

4, Sub crossbeam apply rectangle steel sheet that thickness more than 5mm, stick out in one time.

5, Painting held more tolerance and coherence, can make sure the tank in good situation more than 5 years.



Cabin HW 76 cab, with one bed and air condition, 70°hydraulically tillable to the front as attached photo for ref.
Vehicle Main Dimensions Overall dimensions (L x W x H)mm 11950×2496×3348
Wheel base (mm) 4600+1350
Wheel track (front/rear) (mm) 2022/1830
Approach/Departure angle(°) 16/14
Weight in KGS Tare Weight 12420
payload 20000KGS
Front axles loading capacity 1x7000
Rear axles loading capacity 2x16000
Max. driving speed(km/h) 90
Engine Brand Sinotruk
Model WD615.47
Type 4-stroke direct injection , 6-cylinder in-line, turbo-charging and inter-cooling
Horse Power(HP)  371HP
Emission standard Euro-II
Gearbox 10 Forwards gear & 2 reverse gear
Steering power steering ZF8098 from Germany
Tire 295/80R22.5 tubeless tire, 11 pieces including one spare tire
Tank specification 20,000 liters, tank thickness is 5 mm, seal is 6 mm
Equipped with front(rear,side)sprinkler(sprinkling width>14m )
Equipped with rear working platform with water cannon (range>28m)
Equipped with pump(suction lift>6m)
Equipped with fire valve,water valve,and filter gauze
Production cycle 40 days
