HiperCo27 Soft Magnetic Alloys For Electromagnet Micro Motor Heat Treatment
HiperCo27 Soft Magnetic Alloy for Electromagnet and Micro Motor Applications
Hiperco 27 is a new type of soft magnetic alloy in China even it is already widely introduced by the inventor Carpenter(Hiperoco27). A-ONE ALLOY is among the few manufacturers who are able to produce Hiperco 27 products in China.
FeCo27 is a better choice when the fabrication is in consideration even HiperCo50 is somehow has better permeability and coercive force—even the difference is not big. The magnetic saturation of both alloys is nearly identical. And, Hiperco 27 does not exhibit the brittleness of Hiperco 50.
Euqual grades
1J27, FeCo27, UNS K92650
Chemical composition
| Element | C | Mn | Si | P | S | Cr | Ni | Co | V | Fe |
| Weight(%) | 0.025 | 0.35 | 0.35 | 0.015 | 0.015 | 0.75 | 0.75 | 26.50-28.50 | 0.35 | Rem |
Comparasion between HiperCo50 and HiperCo27
| Parameter | Grade | |
| HiperCo50 | HiperCo27 | |
| Bs | 2.45T | 2.40T |
| Density | 8.2g/cm3 | 7.95g/cm3 |
| Curie Temperature | 980℃ | 925℃ |
| Resistivity | 0.4μΩ·m | 1.9μΩ·m |
| Hc | 72 A/m | 140 A/m |
| Br | 1.45T | 0.85T |
| Magnetostriction | 60x10-6 | 36x10-6 |
| Modulus of elasticity | 30x103 ksi(207GPa) | 24x103 ksi(166GPa) |
| Yield strength | 1280MPa | 1140MPa |
| Tensile strength | 1340MPa | 1150MPa |
| Elongation | 1% | 7% |
Characters of Hiperco27
- High magnetic saturation
- Good mechanical toughness
- Good ductility
- High saturation induction
- High curie temperature: 925℃
Applications
- Motors
- Generators
- Pole pieces
- Relays
- Magnetic bearing
Forms available at A-ONE ALLOY
- Strip
- Bar
- Wire
- Forging
- Machined part
