High Magnetic Saturation 1J27 Soft Magnetic Alloy Cold Rolled Strip Wire Rod
High Magnetic Saturation 1J27 Soft Magnetic Alloy Cold Rolled Strip Wire Rod
1J27 is a Soft Magnetic Alloy in China standard, the main component of this alloy is 27% cobalt, the rest being other elements such as Fe and Ni, Cr, 1J27 alloy is one of XUNSHI's featured products.
Chemical compostions(Weight Percent)
| C | ≤0.030 |
| Mn | ≤0.40 |
| Si | ≤0.35 |
| P | ≤0.015 |
| S | ≤0.015 |
| Cr | ≤0.75 |
| NI | ≤0.75 |
| Co | 26.5-28.5 |
| V | ≤0.35 |
| Fe | Balance |
The magnetic properties of the 1J27 samplse after the heat treatment
| Grade | Forms | Magnetic induction strength (T) in different magnetic field strength (A/m) |
Orthopedic force Hc(A/m) |
||||
| B2400 | B4000 | B8000 | B12000 | B16000 | |||
| Not less than | Not greater than | ||||||
| 1J27 | Cold rolled strip | 1.75 | 1.87 | 2.03 | 2.12 | 2.17 | 280 |
| 1J27 |
Cold wire Hot rolled flat Hot rolled rod |
1.05 | 1.10 | 1.75 | 1.95 | 2.10 | 300 |
Characters
- High magnetic saturation
- Good mechanical toughness
- Good ductility
- High saturation induction
- High curie temperature: 925 °C
Equal grades
- HiperCo27
- Vacofulx27
- FeCo27
- K92650
- 1J27
Forms of supply
- Cold rolled strip
- Cold drawn wire
- Hot rolled flat
- Forged round rod
- Non-standard forgings
