IEC61386-1 Manual Load Heat Resistance Tester with 0.5-4N Weights
Price:
Negotiable
MOQ:
1
Delivery Time:
30 days
Brand:
Sinuo
Product Description
IEC61386-1 Manual Load Heat Resistance Tester with 0.5-4N Weights
This manual load heat resistance tester is designed to evaluate whether non-metallic and composite conduits meet standard requirements for heat resistance under specified load conditions.
Applicable Standards & Scope
Compliant with IEC61386-1:2017 clause 12.2. Suitable for testing metal, non-metallic, and composite conduits or fittings for electrical or communication systems up to AC 1000 V and/or DC 1500 V.
Test Principle
Stacked weights apply different loads via a steel rod onto the specimen. The test must be performed in conjunction with a high-temperature chamber to evaluate heat resistance properties.
Technical Specifications
| Parameter | Specification |
|---|---|
| Test Stations | Single station |
| Control Mode | Manual |
| Specimen Length | 100 ± 5 mm |
| Load Capacity |
0.5 N (self-weight of guide rod), plus slotted hook weights of 0.5 N, 1 N, 2 N and 4 N (one each)
|
| Steel Rod | Ø6 ± 0.1 mm |
| Overall Dimensions | approx. 200 × 200 × 500 mm (W × H × D) |
| Weight | 30 kg |
Optional Configuration
Non-metallic and composite conduits require testing in a high-temperature chamber under conditions specified in Standard Table 2, with maximum temperature tolerance of ±2°C. The high-temperature chamber is available as an optional accessory.
Note: This equipment is designed for laboratory testing of conduit heat resistance in accordance with international standards.
