IEC60884-1 2013 Clause 25.2 20N±0.2N Ball Pressure Test Apparatus
IEC60884-1:2013 clause 25.2 20N±0.2N Ball Pressure Test Apparatus
Product overview:
This Test Apparatus is suitable for testing the heat resistance of all electrical enclosures and external parts made of insulating materials, such as plugs and sockets of various countries, input sockets of appliances, switches, lamps and lanterns, and other similar products.
Meet the standard: IEC60884-1:2006, IEC60598-1:2014, IEC61058-1:2008, IEC60669-1:2007, IEC60320-1:2007
This new version ball pressure test apparatus with an additional supporting rack, after testing, operator take the ball pressure test apparatus out of the heating oven, to avoid damages to other devices or surfaces caused by high temperature due to random placement, operator can place the ball pressure test apparatus on this additional supporting rack.
Test Principle:
This Test Apparatus needs to be tested in a high-temperature chamber at a temperature of 40/70/125±2° for 1 hour, and then dipped in cold water to cool to room temperature within 10s. The diameter of the indentation of the measured sample shall not be greater than 2mm.
Technical Parameters:
| Ball Diameter | Ф5mm, hardening |
| Applied Pressure | 20N±0.2N |
| Support | Ф50×100mm, with temperature measuring hole, made of stainless steel |
| Configuration |
With special plastic case, branded thermocouple for ball pressure tester can be optional |
