SUTEN-W wall mount off grid diy lithium ion renewable power solutions home energy storage system solar batteries

LiFePO4 Battery Pack

Solar Energy Storage System

4800+ Charging and Discharging Cycle Life

10 YEAR WARRANTY

Max. 16 packs can be connected in parallel

Note: Parallel cable included in the package

Specification:

• Model: SUTEN-W LiFePO4 Battery Pack

• Battery Pack Power: 5.12KWh

• Battery Pack Capacity: 100Ah

• Battery Pack Voltage: 51.2VDC

• Battery Pack Charging Voltage: 54.5V

• Battery Pack Discharging Lower Voltage: 41.6V

• Battery Pack Standard Charging Current: 100A

• Battery Pack Max. Charging Current: 100A

• Battery Pack Standard Discharging Current: 100A

• Battery Pack Max. Discharging Current: 100A

• Depth of Discharge: 100%

• Communication Protocol: CAN (RS485 can be customized)

• Battery Pack Configuration: 16 Cells in Series

• Cycle Life: Over 4800 times

• Weight: 55KG (121.25 Lbs.)

• Dimension: 500*170*450mm (21.65*6.69*17.72inch)

• Operation Temperature: -10 ~ 50 ℃ (14F ~ 122F)

• Storage Temperature: -20 ~ 55 ℃ (-4F ~ 131)

• Products Certificates: TUV(IEC62619, IEC62040), CE, ROHS

• Transportation Certificates: UN38.3, MSDS

Communicate inverters list:

Goodwe

Growatt (RS485 protocol and CAN protocol, confirm the models and protocols before purchase.)

Victron

LUX POWER

Sofar

DEYE

Sermatec

RENAC

TBB POWER

SOLIS

SMA

FoxESS

Voltronic (RS485 protocol, need to customize)

Phocos (RS485 protocol, need to customize)

Applications:

Energy Storage

• Solar, wind storage system / on/off-grid energy storage / Business and household

Back-up System and UPS

• Telecome base / CATV system / Computer server center / Medical instrument / Military Equipment

Other Applications

• Security and electronics / LED light / Emergency light
• RV Motorhome / Golf carts battery / Boat Marine Yachts / Electric Skateboard
• LED Backup / Engine starting battery...
