400H Downspout Roll Forming Machine
400H Downspout Roll Forming Machine
|
Types of downspout roll forming machine |
Round type | Square type |
| Sample |  |
 |
| Roller stations | 20 | 20 |
| Thickness | 0.5-0.7mm | 0.5-0.7mm |
| Cutting type | Fly saw cutting /mould cutting | Fly saw cutting / mould cutting |
| Shaft type | solid | solid |
| Roller processing | Quenching,chroming | Quenching,chroming |
| PLC | Delta | Delta |
| Computer screen | Touch screen | Touch screen |
| Main motor | 11KW | 11KW |
| Hydraulic motor | 5.5KW | 5.5KW |
| Board thickness | 18mm | 18mm |
| Machine frame | 400 H steel | 400 H steel |
| Chain size | 1 inch | 1 inch |
Hydraulic decoiler — straightening — Roll forming M/C — PLC control system — Hydraulic pressing&cutting — Production stand
The downspout produced by our downspout roll forming machine with good bending compression performance, flatness is good, automatic fixed length cutting, automatic punching, high degree of automation, fast and convenient installation.
FAQ
1. Q: What is the MOQ?
A: 1 set.
2. Q:Can you make the machine according to my design or photo type?
A: Yes.We have an experienced team for working out the most suitable design and production plan for the machine that you are going to book with us.
3. Q: How can we be assured that you will deliver us quality machine with spare parts?
A:1. Customers to send the technical people to our factory for checking the quality.
2. We can send the technicians to the buyer`s factory for the installation of the machine.
3. Good after-sales service, its free of charge during the warranty period.
