D6*8mm Chemical Stable Single Crystal Scintillators Ce GAGG Crystal
Price:
Negotiable
MOQ:
1 Piece
Delivery Time:
4 weeks
Brand:
Crystro
Product Description
Good chemical stability Single Crystal Scintillators Ce GAGG Crystal
GAGG(Ce) doped with Ce is a newly developed scintillator. It is one of the brightest available scintillators with an emission peak at 520nm. GAGG(Ce) has good stopping power, is physically rugged, and well suited to a broad range of applications.
Apart from the high light yield, good energy resolution, high effective atomic number, fast scintillation response, chemical stability also ruggedness, and capability of large crystal growth are very important properties for Ce: GAGG crystals as well.
Crystro offers:
| Orientation Tolerance | ＜0.5° |
| Thickness/Diameter Tolerance | ±0.05mm |
| Parallel | 30" |
| Perpendicular | 15' |
| Surface Quality | 10/5 |
| Clear Aperture | ＞90% |
| Chamfer | ＜0.1*45° |
| Max Dimensions | MaxΦ 60mm |
Features :
- High output :>50000 (Photons/MeV)
- High density: Good absorbers with good stopping powers
- High energy resolution
- Emission peak around 520 nm
Main Application:
- Medical Imaging - PET, PEM, SPECT, and CT
- Specialist applications in high energy, nuclear, space, and medical physics
- Scanning electron microscopy (SEM)
Product details:
