Full Automatic Scaffold Plank Metal Roll Forming Machine 5T

Full Automatic Scaffold Plank Roll Forming Production Line With Electrical Welding Machine

Crocodile mouth steel scaffolding plate, construction steel scaffolding plate, marine steel scaffolding plate, non-slip steel scaffolding plate, European style steel scaffolding plate, etc., the current market demand is very large, footplate as a new type of engineering materials, mainly in metallurgy, energy, shipping, municipal, petrochemical, transportation, building materials, national defense and other fields used as platforms, trestles, bridges, highway guardrails, ditch covers, fences, gates and other facilities. On the above elaboration, the current domestic demand for non-slip pedal is large, covering many industries, the traditional processing and production of pedal production process, has not been able to meet the needs of the current era of development. The new profit point for enterprises lies in reducing labour, improving production efficiency, improving product quality, saving raw materials, etc. (scaffolding plank roll forming machine/ scaffolding plank bending machine)

Components of the automatic production line for anti-slip steel scaffolding plates.

It consists of automatic discharge machine, guiding frame, levelling machine, feeding machine, continuous punching device, forming part, sizing and cutting part, receiving table, electrical control cabinet and other components.

Process flow of automatic production line for anti-slip steel scaffolding plates.

Automatic uncoiling - nine-axis levelling - servo feeding - continuous punching device - roll forming - sizing and cutting - receiving table; electrical control system(steel scaffold board roll forming machine/steel scaffold board bending machine)

Flow Chart Of Full Automatic Scaffold Plank Roll Forming Production Line With Electrical Welding Machine

5T hydraulic-Sevo motor-Hydraulic punch-Roll forming machine-Hydraulic cut-Electric welding machine-Outer table

Main Technical Parameters

Pictures of Full Automatic Scaffold Plank Roll Forming Production Line With Electrical Welding Machine
