Siemens S2000 Ultrasound TR Board 7475028
Siemens S2000 Ultrasound TR Board
1. Lead time: 2-4 days
2. Warranty: 60 days
3. Part number: 7475028
Related information
Siemens S2000
- Hardware design:
The machine is designed according to the theory of adaptive ergonomics. The machine is compact in appearance and flexible in operation.
The probe interface unit, electrical unit and input and output unit are connected through the mother board to realize the transmission of the control ultrasonic signal to the processing of the echo signal, and finally form the video and audio signals required for clinical diagnosis in the display and other terminals.
- Hardware structure——Electrical Unit (E-Module) :
It includes a series of core control and processing boards for ultrasonic imaging, such as transmitting/receiving board (TR), receiving control board (RC), continuous wave board (CB), post stage board (BE), video interface board (VI) and real-time control board (RM), etc. These boards jointly realize the functions of transmitting, receiving, processing and imaging of ultrasonic signals.
Other ultrasound parts related to Siemens that we can offer:
| Brand | Machine type | Description |
| Siemens | S1000/S2000 | RM200 (10038592) |
| Siemens | S1000/S2000 | RM220 (10853882/10439172) |
| Siemens | S2000 | RM300 (10852163) |
| Siemens | S2000 high version/S3000 | RM301 (10854749) |
| Siemens | S1000/S2000 | VI Board (10039639/10039638) |
| Siemens | S2000 | TI Board 10040951 |
| Siemens | S2000 | Control Panel (P/N:11287361) |
| Siemens | Antares, S2000/Sequoia C512 | monitor (P/N: 10437579) |
| Siemens | S2000 | CB (P/N:10041510) |
| Siemens | S2000 | Transmit Receiver Board,(07475028,rev 03) |
| Siemens | S2000 | RM |
| Siemens | Antares | RM165 (10027776) |
| Siemens | Antares | RM167 (10035299/200622716597) |
| Siemens | Antares/S2000 | RM200 (10044096/10038592/10439676) |
