BMS 100ah Lithium Ferro Phosphate Battery In Circuit Protection
FEATURES
High cycle life
4000 cycles @80% DoD for effectively lower total of ownership cost
Longer service life
Low maintenance batteries with stable chemistry.
Built in circuit protection
Battery Management System (BMS) is incorporated against abuse.
Extreme heat tolerance
Suitable for use in a wider range of applications where ambient temperature is unusually high: up to +60°C.
ELECTRICAL PERFORMANCE
| Nominal Voltage | 51.2 V |
| Nominal Capacity | 100 Ah |
| Capacity @ 20A | 300 min |
| Energy | 5120 Wh |
| Communication | CAN2.0/RS232/RS485 |
| Resistance | ≤45 mΩ @ 50% SOC |
| Efficiency | >96% |
| Module Parallel | Up to 3 packs |
TEMPERATURE PERFORMANCE
| Discharge Temperature | -4 ~ 131 ºF (-20 ~ 55 ºC) |
| Charge Temperature | -4 ~ 113 ºF (0 ~ 45 ºC) |
| Storage Temperature | 23 ~ 95 ºF (-5 ~ 35 ºC) |
| BMS High Temperature Cut-Off | 149 ºF (65 ºC) |
| Reconnect Temperature | 131 ºF (55 ºC) |
HEATING FOIL PERFORMANCE
| Heating Temperature Range | -4 to 41 ºF (-20 to 5 ºC) |
| Heating Time | Approximately 1 hour @ 7.5 A |
| BMS Heating Foil Cut-Off | 158 ºF (70 ºC) |
FAQ:
Q 1. What is your warranty of battery?
A 1: Our standard warranty is 3 years. Our battery lifespan can be used for at least 10 years for normal 1 cycles per day.
Q 2. Does Must battery include BMS?
A 2: Our Wall mounted and Rack mounted Lithium battery include BMS.
Q 3. Does the battery have a monitoring function?
A 3: Lead Acid Replacement Lithium Battery has Bluetooth monitoring function.
Q 4: Does Must support door to door shipping?
A 4: Yes. Normally when the goods are less than 30kg, we will ship by air, and when the goods are more than 30kg, we will ship by sea.
Q 5: What grade of batteries do Must use?
A 5: We use Grade A Cells (CATL/EVE)
Q 6: What is the number of cycles of the battery?
A 6: 4000 cycles @80% DoD
Operation Notice
♦ Do not heat the battery directly or thrown into a fire.
♦ Do not assemble or store in high temperature (over 55 °C) environment
♦ Do not short-circuit the battery directly.
♦ Do not use acid corrosion of the battery casing.
♦ Do not throw it into water or put in wet environment.
♦ Do not knock, impact the battery.
♦ Do not anatomy cell or change the internal structure of the battery.
