50Ah Li Ion Lithium Battery
APPLICATIONS
Lithium Iron Phosphate can be used in most applications that use Lead Acid, GEL or AGM type batteries.
Suitable applications include:
•Caravan
•Marine
•Golf Car
•Buggies
•Solar Storage
•Remote Monitoring
•Switching applications and more
COMPLIANCE
| Certifications | CE (battery) UN38.3 (battery) UL1642 & IEC62133 (cells) |
| Shipping Classification | UN 3480, CLASS 9 |
MECHANICAL PERFORMANCE
| Dimension (L x W x H) | 228 x 144 x 210 mm 9.0 x 5.7 x 8.3” |
| Approx. Weight | 27.8 lbs (7.5 kg) |
| Terminal Type | DIN POST |
| Terminal Torque | 80 ~ 100 in-lbs (9 ~ 11 N-m) |
| Case Material | ABS+PC |
| Enclosure Protection | IP65 |
TEMPERATURE PERFORMANCE
| Discharge Temperature | -4 ~ 131 ºF (-20 ~ 55 ºC) |
| Charge Temperature | -4 ~ 113 ºF (0 ~ 45 ºC) |
| Storage Temperature | 23 ~ 95 ºF (-5 ~ 35 ºC) |
| BMS High Temperature Cut-Off | 149 ºF (65 ºC) |
| Reconnect Temperature | 131 ºF (55 ºC) |
FAQ:
Q 1. What is your warranty of battery?
A 1: Our standard warranty is 3 years. Our battery lifespan can be used for at least 10 years for normal 1 cycles per day.
Q 2. Does Must battery include BMS?
A 2: Our Wall mounted and Rack mounted Lithium battery include BMS.
Q 3. Does the battery have a monitoring function?
A 3: Lead Acid Replacement Lithium Battery has Bluetooth monitoring function.
Q 4: Does Must support door to door shipping?
A 4: Yes. Normally when the goods are less than 30kg, we will ship by air, and when the goods are more than 30kg, we will ship by sea.
Q 5: What grade of batteries do Must use?
A 5: We use Grade A Cells (CATL/EVE)
Q 6: What is the number of cycles of the battery?
A 6: 4000 cycles @80% DoD
Q 7: What export certificates do lithium batteries have?
A 7: DG Report, CE (battery), UN38.3 (battery), UL1642 & IEC62133 (cells), Msds
