Rack Mounted Lithium Iron Phosphate UPS , Lithium Phosphate Cell 50AH 48V
Price:
USD439/pc
MOQ:
100
Delivery Time:
10-15days
Brand:
MUST
Product Description
MUST Lithium Battery Rack Mounted ups 50AH 48V Lithium Battery Rack wall
Product Description
LP18-4850 (51.2V/50Ah)
- Lithium-ion batteries are rechargeable batteries that use lithium as one of their active components. Lithium Iron Phosphate Batteries are a type of lithium-ion batteries known for their long life and inherent safety. Lithium-ion (Li-ion) batteries are used in many products such as electronics, toys, wireless headphones, handheld power tools, small and large appliances, electric vehicles and electrical energy storage systems.
Pictures
Detailed parameters
ELECTRICAL PERFORMANCE
| Nominal Voltage | 51.2 V |
| Nominal Capacity | 50AH |
| Capacity @ 20A | 150 min |
| Energy | 2560Wh |
| Communication | CAN2.0/RS232/RS485 |
| Resistance | ≤45 mΩ @ 50% SOC |
| Efficiency | >96% |
| Module Parallel | Up to 3 packs |
CHARGE PERFORMANCE
| Recommended Charge Current | 20A |
| Maximum Charge Current | 50A |
| Recommended Charge Voltage | 57.6V |
| BMS Charge Cut-Off Voltage | <58.4 V (3.65V/Cell) |
| Reconnect Voltage | >57.6 V (3.6V/Cell) |
| Balancing Voltage | <57.6 V (3.6V/Cell) |
| Maximum Batteries in Series | 16 (*Consult MUST) |
MECHANICAL PERFORMANCE
| Dimension (L x W x H) |
482*410*133mm
19.0 x 16.1 x 5.2”
|
| Approx. Weight | 11.4 lbs (25 kg) |
| Terminal Type | DIN POST |
| Terminal Torque | 80 ~ 100 in-lbs (9 ~ 11 N-m) |
| Case Material | SPPC |
| Enclosure Protection | IP65 |
DISCHARGE PERFORMANCE
| Maximum Continuous Discharge Current | 50 A |
| Peak Discharge Current | 60 A (3s) |
| BMS Discharge Cut-Off Current | 75 A (300ms) |
| Balancing open voltage | 55.2V (3.45V/Cell) |
| Recommended Low Voltage Disconnect | 44 V (2.75V/Cell) |
| BMS Discharge Cut-Off Voltage | >32.0V (2s) (2.0V/Cell) |
| Reconnect Voltage
|
>40.0 V (2.5V/Cell) |
| Short Circuit Protection | 250 ~ 500 μs |
TEMPERATURE PERFORMANCE
| Discharge Temperature | -4 ~ 131 ºF (-20 ~ 55 ºC) |
| Charge Temperature | -4 ~ 113 ºF (0 ~ 45 ºC) |
| Storage Temperature | 23 ~ 95 ºF (-5 ~ 35 ºC) |
| BMS High Temperature Cut-Off | 149 ºF (65 ºC) |
| Reconnect Temperature | 131 ºF (55 ºC) |
HEATING FOIL PERFORMANCE
| Heating Temperature Range | -4 to 41 ºF (-20 to 5 ºC) |
| Heating Time | Approximately 1 hour @ 7.5 A |
| BMS Heating Foil Cut-Off | 158 ºF (70 ºC) |
