12 Volt Rack Mount Lithium Battery Pack 200AH High Safety
Price:
Negotiable
MOQ:
1
Delivery Time:
30-45 working days
Brand:
MUST
Product Description
MUST Rack Mount Lithium Battery Lifepo4 512.V 200AH Battery Pack
MUST Lithium Battery
Technical Data
ELECTRICAL PERFORMANCE
| Nominal Voltage | 51.2 V |
| Nominal Capacity | 200 Ah |
| Capacity @ 20A | 600 min |
| Energy | 10240 Wh |
| Communication | CAN2.0/RS232/RS485 |
| Resistance | ≤45 mΩ @ 50% SOC |
| Efficiency | ＞96% |
| Module Parallel |
Up to 8 packs
|
DISCHARGE PERFORMANCE
| Maximum Continuous Discharge Current | 100 A |
| Peak Discharge Current | 110 A (3s) |
| BMS Discharge Cut-Off Current | 150 A (300ms) |
| Balancing open voltage | 55.2V (3.45V/Cell) |
| Recommended Low Voltage Disconnect | 44 V (2.75V/Cell) |
| BMS Discharge Cut-Off Voltage | >32.0V (2s) (2.0V/Cell) |
| Reconnect Voltage | >40.0 V (2.5V/Cell) |
| Short Circuit Protection |
250 ~ 500 μs
|
TEMPERATURE PERFORMANCE
| Discharge Temperature | -4 ~ 131 ºF (-20 ~ 55 ºC) |
| Charge Temperature | -4 ~ 113 ºF (0 ~ 45 ºC) |
| Storage Temperature | 23 ~ 95 ºF (-5 ~ 35 ºC) |
| BMS High Temperature Cut-Off | 149 ºF (65 ºC) |
| Reconnect Temperature | 131 ºF (55 ºC) |
