FGG Circular Push Pull Connectors
FGG EGG 2B Push Pull Circular Connector Compatible With Lemo Connector
Mechanical Details
| Mechanical Details | |
| Shell Style | Straight plug, with cable collet |
| Key | 1 key(alpha=0°；plug: male contacts, receptacle:female contacts) |
| Housing material | Brass Cr plated |
| Housing color | Grey-White |
| Cable OD max | Φ5.0mm |
| Jacket | Grey, black |
| Endurance | 5000 mating cycles |
| Operation temp.(min) | -20℃ |
| Operation temp.(max) | 120℃ |
| Humidity(max) | <=95%(at 60℃/140F) |
Different Series quick details
| Series | Cable outer diameter range(mm) | Pin Number |
INGRESS PROTE CTION |
Temperature range | |||
| cable clamp | cable clamp with bend relief | ||||||
| Min | Max | Min | Max | ||||
| 00 | 1.1 | 3.4 | 1.1 | 3.4 | 2,3,4pin | ||
| 0B | 1.5 | 5.5 | 1.5 | 5.0 | 2,3,4,5,6,7,9 pin | IP50 | -55°C~250°C |
| 1B | 2.2 | 7.5 | 2.2 | 7.0 | 2, 3, 4, 5, 6, 7,8,10,14,16pin | ||
| 2B | 1.5 | 9.7 | 1.5 | 9.0 | 2, 3, 4, 5, 6, 7,8,10,12,14,16, 18,19pin | ||
| 3B | 4.1 | 11.7 | 4.1 | 11.0 | 2, 3, 4, 5, 6, 7,8,10,12,14,16, 18, 20,22,24,26,30 pin | ||
| 0K | 1.0 | 5.0 | 1.0 | 5.0 | 2,3,4,5,6,7,9 pin | IP66-IP68 | -55°C~200°C |
| 1K | 1.3 | 8.5 | 1.3 | 8.5 | 2, 3, 4, 5, 6, 7,8,10,14,16pin | ||
| 2K | 1.3 | 10.5 | 1.3 | 10.5 | 2, 3, 4, 5, 6, 7,8,10,12,14,16, 18,19pin | ||
| 3K | 2.6 | 15.0 | 2.6 | 15.0 | 2, 3, 4, 5, 6, 7,8,10,12,14,16, 18, 20,22,24,26,30 pin | ||
Main Features
| 1. Push pull locking metal connector, cable to cable connector, free socket, inline connector |
| 2. Safe push-pull (plug-in) self-locking system. |
| 3. Welding and printed circuit board pin cores (straight and bent). |
| 4. It is convenient for high-density installation and saves space. |
| 5. Various multi-core types can be produced, and can be specially customized according to customer requirements |
| 6. Various key positions’ different positioning selection can prevent mixed insertion between similar connectors. |
| 7. 360 degree shielding provides comprehensive EMC protection. |
Our Advantages
1.) More competitive price.
2.) 1 pcs samples available.
3.) OEM & ODM service acceptable.
4. ) With a wide range of products, complete models, reasonable prices and high quality.
5.) High quality after-sales service.
Services Offered
OEM/ODM medical cables and accessories, circular push pull connectors and other connector products.
Design and development with our customer, we work with customer’s idea and requirement combining with
our manufacturing experience and engineering expertise to offer a tailored connecting solution from start to finish.
FAQ
Q: Are you trading company or manufacturer?
A: We are original manufacturer. We can do OEM/ODM service.
Q: What’s your delivery time ?
A: sample for 3-5 working days, mass production for 5-20 working days.
Q: What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery.
Q: Can we visit your factory?
A: Of course yes, we will prepare for everything in advance if it is necessary.Generally, It is requirement that
customers must have build agency relationship or business relationship with our company.
