10Gbit/S Surge Protection 2KV 802.3BT PoE Injector For VoIP Phone
IEEE802.3bt Poe Injector Procet Indoor Wall-mounted-Surge protection 2Kv VoIP Phone Wilress AP Security cameraS
Froducts Features:
1.PT-PSE104GB-60 is a single port midspan Injector with 4 Pair PoE up to 60 watts of power at 55 VDC at 1.1 amp.
2.Designed for the PoE++ powered 60W PoE Powered Devices (PDs), such as IP Cameras, wireless APs, Microwave radio, IoT application, door locks, displays, POS, and information kiosks, It supports 10/100/1000Mbps/10GBps of data rates. Fully comply with IEEE802.3bt and remains compatible with any IEEE802.3af/at compliant devices. Equipped detecting chip inside, which will detect and classify PD before powering it, protecting non PoE device.
3.Enclosed in an IP40 fire retardant plastic case, designed for indoor installation with Wall-mounted. It operates with a wide input voltage of 100-240 VAC. The effective distance limitation of 100 meters over Cat5e/Cat6 cables can be extended with the PT-PEX-01G-OT(Outdoor or Indoor PoE Extender).
| Name: |
IEEE802.3bt Poe Injector Procet Indoor Wall-mounted-Surge protection 2Kv VoIP Phone Wilress AP Security cameraS |
| Ports Conditioning: | - LAN Port*2, AC Input Port*1, PoE Output Port*2 |
| Pass Through Data Rateshrough Data Rates: | - 10/100/1000 Mbps |
| Input: | AC Input Voltage: 100-240 Vac Frequency: 50/60Hz Typ. AC Input Current:1.5A |
| POE Surge Protection: | Otected Line:Protected Line: 1,2,3,4,5,6,7,8 Common Mode Surge Protection(10/700us): 6KV Differential Mode Surge Protection (10/700us): 1.5KV 1,2,3,4,5,6,7,8 Common Mode Surge Protection(10/700us): 10KV Differential Mode Surge Protection (10/700us): 6 |
| Safety Approvals: | CE, FCC, UL |
| Key Features: | I Dual-port Optional PoE - 30W/60W Application - AC Port 4KV Lighting Protection |
| Regulatory Compliance: | IEEE802.3bt RoHS Compliance WEEE Compliance |
| Output: | Pin Assignment And Polarity: - 4/5(+), 7/8(-) And 3/6(+),1/2(-) - Output Power Voltage: 55Vdc - User Port Power: 30W@2-PoE Or 60W@1-PoE |
| Working Environment: | Operating Temperature: -40℃ To 65℃ Operating Humidity: 20% To 80%, Non-condensation Storage Temperature: -40℃ To 85℃ Storage Humidity: 10% To 90%, Non-condensation Operating Altitude: Up To 5000meters |
| Mechanical Characteristics: | Case: Plastic - Color: Black - Mounting: Rack-mounted / Wall-mounted - IP Rated: IP20 - Connectors: Shielded RJ-45*4, AC*1 - Size: 208mmX 85mmX 46mm |
| LED Indicator: | Power Indicator: Green PoE Load Indicator: Green SFP Fiber Indicator: Green PoE Data Indicator: Yellow |
Our Services & Strength
*. Experienced Techncial team, to provide kinds of solutions
*. Provided authorized certifications
*. 100% Full Burn-In Testing, stictly inspect and control during production
2. Sample terms
*Common sample:2pcs are free offered, the buyer shall pay for the shipping cost and Tax; Leadtime within
*. Special Sample: the buyer shall pay for the sample cost, shipping cost, Tax, R&D cost (if caused)
Leadtime will be confirmed when the project starting
3. Mass production
20-25 working days, from the day got the confirmed order and payment
4. Shipment
By Sea, By Air, By Train, By Express ect
5. Payment: T/T in advance, L/C
