ASTM SGCC Flat GI Hot Dip Galvanized Steel Sheet
Price:
$0.95/kg ; $880/Ton
MOQ:
500kg
Delivery Time:
3-7work days
Brand:
Baosteel
Product Description
Galvanized coils, the sheet steel is immersed in a molten zinc bath to make a sheet of zinc coated on its surface. It is mainly produced by continuous galvanizing process, that is, the rolled steel plate is continuously immersed in a plating tank with molten zinc to make galvanized steel plate; alloyed galvanized steel plate.
This kind of steel plate is also produced by hot dip method, but immediately after it is out of the tank, it is heated to about 500 ℃ to form an alloy film of zinc and iron. This galvanized coil has good paint adhesion and weldability
| Yield strength(Mpa) | 140~300 |
| Tensile strength(Mpa) | 270~500 |
| Elongation(%) | ≥22 |
| Component(Wt%) | C | Si | Mn | P | S | Ti |
| ≤0.12 | ≤0.5 | ≤0.6 | ≤0.1 | ≤0.045 | ≤0.3 |
| Average weight of upper Surface coating (g/㎡) | Average weight of lower Surface coating (g/㎡) | coating form |
| 30~225 | 30~225 | Equal thickness |
| Average weight of upper Surface coating (g/㎡) | Average weight of lower Surface coating (g/㎡) | coating form |
| 30~150 | 30~150 | Poor thickness |
| The maximum difference thickness ratio is: | 1:3 | --- |
| Product Name | Zinc Coated Hot Dipped Galvanized Steel Strip / Coil / GI coil |
| Technical Standard | EN10147, EN10142, DIN 17162, JIS G3302, ASTM A653 |
| Steel Grade | DX51D, DX52D, Dx53D, DX54D, SGCC, SGHC, SGCH |
| Type | Coil/Sheet/Plate/Strip |
| Thickness | As customer's requirement |
| Width | 50mm-1500mm, according to customer's requirement |
| Type of Coating | Hot Dipped Galvanized Steel(HDGI) |
| Zinc Coating | 30-275g/m2 |
| Surface Treatment | Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U) |
| Surface Structure | Normal spangle coating(NS), minimized spangle coating(MS), spangle-free(FS) |
| Quality | Approved by SGS,ISO |
| Coil Weight | 1-20 metric ton per coil |
| Package | Water proof paper is inner packing,galvanized steel or coated steel sheet is outer packing , side guard plate,then wrapped by several steel belt. Or according to customer's requirement |
| Export market | Europe, Southeast Asia, Middle East, South America, North America, etc |
