High Magnesium 5083 Aluminum Alloy Sheet Plate 65mm
Price:
$0.83/Kilograms >=500 Kilograms
MOQ:
500 Kilograms
Delivery Time:
Negotiable
Brand:
MPC
Product Description
5083 aluminium alloy
Characteristics and scope of application:
1. It is a high magnesium alloy with good strength, corrosion resistance and machinability. After anodizing Beautiful surface. The arc welding performance is good. The main alloy element in 5083 alloy is magnesium, which has good corrosion resistance and weldability.Performance, and medium strength. Due to its excellent corrosion resistance, 5083 alloy is widely used in marine applications, such as ships, automobiles, etc.For aircraft weldments and Metro light rail, pressure vessels (such as liquid tank cars, refrigerated cars and refrigerated containers) with strict fire protection and refrigeration are required.Installation, TV Tower, drilling equipment, transportation equipment, missile parts, armor, etc;
2. 5083 is an Al Mg Si alloy, which has a wide range of applications, especially in the construction industry. It is the most promising alloy Alloy. It has good corrosion resistance, weldability, cold workability and medium strength. The main alloying elements of 5083 are Magnesium, with good formability, corrosion resistance, weldability and medium strength, is used to manufacture aircraft oil tank, oil pipe and Sheet metal parts of traffic vehicles and ships, instrument, streetlight bracket and rivet bracket, hardware products, electrical shell, etc;
3. Al-Mn series alloy is the most widely used antirust aluminum. This alloy has high strength, especially strong fatigue
resistance Degree: high plasticity and corrosion resistance, no heat treatment strengthening, good plasticity in semi cold work hardening, low plasticity in cold work hardening, resistance Good corrosion, good weldability, poor machinability and polishing.It is mainly used for high plasticity and good welding Low load parts, such as mailboxes, gasoline or lubricating oil pipes,various liquid containers and their He uses deep drawing to make small load parts: wire is used to make rivets.
resistance Degree: high plasticity and corrosion resistance, no heat treatment strengthening, good plasticity in semi cold work hardening, low plasticity in cold work hardening, resistance Good corrosion, good weldability, poor machinability and polishing.It is mainly used for high plasticity and good welding Low load parts, such as mailboxes, gasoline or lubricating oil pipes,various liquid containers and their He uses deep drawing to make small load parts: wire is used to make rivets.
|
Component(Wt%)
|
|
|
|
|
|
|
|
|
||||||||
|
Si(≤)
|
Fe(≤)
|
Cu(≤)
|
Mn(≤)
|
Zn(≤)
|
Cr(≤)
|
Ti(≤)
|
Mg(≤)
|
Al(≤)
|
||||||||
|
0.40
|
0.00~0.40
|
0.10
|
0.40~1.0
|
0.25
|
0.05~0.25
|
0.15
|
4.0~4.9
|
All the rest
|
||||||||
|
Mechanical properties
|
Yield strength σ b(Mpa)
|
≥270
|
|
Mechanical properties
|
Tensile strength σ 0.2 (Mpa)
|
≥110
|
|
|
Elongation δ 10(%)
|
≥20
|
|
|
Elongation δ 5(%)
|
≥12
|
|
|
Temperature
|
holding time
|
cooling mode
|
|
Homogenization annealing
|
460~475℃
|
12~14h
|
Air cooling
|
|
Rapid annealing
|
350~410℃
|
30~120min
|
Air or water cooling
|
|
High temperature annealing
|
350~420℃
|
10~30/2~10min
|
Air cooling
|
|
Low temperature annealing
|
250~300℃
|
1~2h
|
Air cooling
|
