7.5KW Grain Silo Roll Forming Machine , Grain Silo Making Machine

Main technical parameters

1. Size: 8900mm × 2250mm × 2300mm

2. Total Weight: about 13000KG

3. Main Motor Power: 16.7KW

4. forming power is 7.5kw ; bending power is 4.0kw;

5. cutting power is 3.0kw;  conical power is 2.2kw

6. Working Speed:

7. Straight sheet: 15m/min; Arch sheet: 13m/min ; Sewing: 6m/min

8. Material of rollers: 45# steel, quenched HRC 58-62

9. Material of roller shafts: 45# steel, adjusted

10. Material of cutting blade: Cr12 steel

11. Step of rollers: 15 steps

12. Feeding Width: 600mm

13. Effective Width: 305mm

14. The depth of the groove: 140mm

15. Thickness of the coil: 0.6-1.5mm

16. Operating factor of the panel: 51%

Main Part

1. Manual decoiler

2. Main forming machine

3. Curving machine

4. Seam machine
