Circular Metal Sawing Machine
Automatic feeding circular cold saw for cutting metal materials CNC flying saw cutting
Introduction
The equipment is designed to enable fast blade changes, minimize downtime and ensure smooth and uninterrupted operation. Synchronization is achieved by using an AC servo motor control system for fastest response time and best results.
| material | Q195 Q235 SPCC | |
|
Cutting range |
Round tube:MAX114mm | thick:0.5～4.0mm |
| Square tube:MAX90×90mm | thick:0.5～4.0mm | |
| Rectangular tube:MAX 50×90mm | thick:0.5～4.0mm | |
| Production speed | 80m/min(length 6 meter,dia.≤25mm) | |
| Cutting length | 1500-99999mm | |
| Length tolerance | ±1.5mm(speed diviation not more than 2%)； | |
| Feeding direction | ||
| Operation height | 800mm | |
| Cutting burr height | Max:0.25mm； | |
| Power supply |
AC380V,3PH,50HZ |
|
| Mechanical length | 5420*1480*1380mm(as per final drawing) | |
|
Motor list |
Drive:18.5KW | PHASE servo motor |
| feed: 3.3KW | PHASE servo motor | |
| saw: 22KW | PHASE servo motor | |
| Linear guide | Hiwin Chinese Taiwan | |
| Clamp | hydraulic pressure | |
| Clamp block model | tape shape to avoid scratching the steel pipe | |
| Oil supply system | Auto oil filling | |
| Saw blade | High speed steel | |
| main shaft gearbox | Special made | |
| Gear rack | KH from Chinese Taiwan | |
| Cable protection | Drag chain | |
| Carriage protection | Safety bumpers for carriage are equipped at both ends | |
| Equipment document | User’s manual & electrical diagram | |
Features
1. The sawing method of cold milling is adopted. The sawing process generates very little heat, which avoids the change of internal stress and material structure at the cut section. At the same time, the saw blade has a small pressure on the steel pipe, which will not cause the pipe wall orifice. deformed.
2. The quality of the cut end face of the workpiece processed by the high-speed steel cold cutting saw is good
3. The service life is long. The saw blade grinding machine can be used to grind the teeth for many times. The service life of the polished saw blade is the same as that of the new saw blade. Improve production efficiency and reduce costs.
Our service
1. Professional pre-sales consultation and after-sales service to help you find the best solution
2. Discuss technical details with our professional engineers
3. Strictly control the quality and production plan of the cold flying saw. You will be kept informed of any progress
4. Check the cold flying saw before shipment
5. After the warranty period, spare parts are provided at cost
6. Professional engineers help you increase production, reduce waste and reduce costs
7. Control the production progress and quality of the machine, and provide you with detailed information in time
