50x80mm Cold Saw Cutting Machine Rectangular Flying Saw Cutter

Price Negotiable
Price: Negotiable
MOQ: 1 set of
Delivery Time: 15-30 work days
Brand: JCCS
Product Description

Metal Steel Cold Cut Saw Steel Pipe Cutter Pipe Cold Cut Wire Forming Machine




Introduction
The cold cutting flying saw adopts professional motion control technology, with higher tracking and synchronization accuracy to ensure cutting accuracy. The servo feeding mechanism completes the cutting process, which not only meets the needs of the cutting process, but also increases the service life of the cutting blade. User-friendly man-machine interface, parameter adjustment is convenient and quick. Adopt cold chip method, low noise, high safety, smooth cutting end face, no burr.



Material Q195 Q235 SPCC

Cutting range

Round tube:MAX89mm thick:0.5~4.0mm
Square tube:MAX65×65mm thick:0.5~4.0mm
Rectangular tube:MAX 50×80mm thick:0.5~4.0mm
Length tolerance ±1.5mm(speed diviation not more than 2%);
Operation height 750mm
Power supply AC380V,3PH,50HZ



Motor list

Drive:18.5KW PHASE servo motor
feed: 3.3KW PHASE servo motor
Clamp hydraulic pressure
Oil supply system Auto oil filling
Gear rack KH from Chinese Taiwan
Cable protection Drag chain
Equipment document User’s manual & electrical diagram


Features

1. Ability to handle products of various shapes: round, square, rectangular, open profiles
2. High cutting precision
3. Remote monitoring function, which can remotely evaluate the on-site operation status
4. After programming, there is no need for the operator to always be at the console





Our advantage

1. Advanced production testing equipment and strict quality control system ensure good and stable product quality.
2. Cost-effective and long-life saw blades help customers save more money.
3. The steel plate is chrome-plated, the blade is rust-proof, and the appearance is better.
4. Factory direct sales ensure more professional service and prompt delivery time.
