Fiber Optic Patch Leads 2cores LC APC To SC APC OM4 50/125um LSZH Purple Duplex
|
Item
|
SM(Single Mode)
|
MM(Multimode)
|
|||
|
Fiber Cable Type
|
G652/G655/G657
|
OM1
|
OM5/OM2/OM3/OM4
|
||
|
Fiber Diameter (um)
|
9/125
|
62.5/125
|
50/125
|
||
|
Cable OD (mm)
|
0.9/1.6/1.8/2.0/2.4/3.0
|
||||
|
Endface Type
|
PC
|
UPC
|
APC
|
UPC
|
UPC
|
|
Typical Insertion Loss (dB)
|
<0.2
|
<0.15
|
<0.2
|
<0.1
|
<0.1
|
|
Return Loss (dB)
|
>45
|
>50
|
>60
|
/
|
|
|
Insert-pull Test (dB)
|
<0.2
|
<0.3
|
<0.15
|
||
|
Interchangeability (dB)
|
<0.1
|
<0.15
|
<0.1
|
||
|
Anti-tensile Force (N)
|
>70
|
||||
|
Temperature Range (℃)
|
-40~+80
|
||||
| ange of Mode | Single mode or Multi mode |
| Cable Type | Simplex, Duplex Ziocord. or Multi-cores |
| Connector Style | SC, FC, ST, LC, MTRJ, E2000, MU, MPO /MTP.etc |
| Polish or Ferrule Interface Type | PC, UPC, APC |
| Cable Diameter | 0.9mm, 1.2mm, 1.6mm, 1.8mm,2.0mm, 3.0mm |
| Outer Jacket | PVC /LSZH/OFNP |
| Jacket Color | SM Yellow | OM1, OM2 Orange | OM3 Aqua | OM4 Aqua or Violet | OM5 Lemon Green |
| Durability | 500 cycles(0.2 dB max increase). 1000mate/de mate cycles |
| Operating Temp. | -25℃ to +70℃ |
| Storage Temp. | -40℃ to +85℃ |
- 4-48 core 0.9, 2.0, 3.0 break-out leg available
- high fiber density,Small volume,
- Low insertion loss and high reflection loss
- High reliability and Excellent mechanical capability
- High density cable wiring system
- Switching between trunk line and distribution line
- High integrated equiement and devices
- Local/wide area networks
The reason why Choose us:
1. Our shipping time is strictly controlled
2. We can provide customized service, according to the order requirements, can be equipped with a salesman and an engineer
3. Our company has rich export experience and is familiar with the customs policies of various countries
4. Large product inventory with massive production line
5. China's professional gas detection leader
6. Product distribution involves multi-fields, dozens of countries including some developed countries.
FAQ
1. Are you factory direct?
as a professional fiber patch cord manufacturer, specialized in Fiber Optic Patch Cord,MPO, Fiber Optic PLC Splitter. Our products are mainly exported to Europe, South America, and some other countries and areas.
2. What is your main products?
Outdoor fiber optic cables indoor fiber optic cables FTTH Drop cables ADSS
Indoor armored patch cords fiber cable Optical patch cords Sc LC FC ST MTP MPO optical patch cord
3. Product quality guarantee period?
20 years Guarantee for fiber optic cable
4. Do you have certificate for raw material?
We build long-term relationship cooperation with qualified ISO9001 ROHS raw material suppliers
