Cermet Alloy Cold Cut Saw Blade For High Carbon Steel Cutting metal cold saw
Price:
Negotiation
MOQ:
5 pieces
Delivery Time:
Subject to stock status
Brand:
KWS
Product Description
Cermet Alloy Cold Cut Saw Blade For High Carbon Steel Cutting Metal Cold Saw
PRODUCT DESCRIPTION
ADVANTAGES
1. Advanced production & detection equipments and strict quality control system to ensure quality excellent and stable.
2. High cost effective saw blades with long life helping customer save more money.
3. Low noise, smooth cutting surface, no bur, no deformation and constantly teeth .
4. Special tooth design, cutting fast.
SPECIFICATION
![Cermet Circular Cold Saw Blade for Carbon Steels Cutting with Special Tooth Feature]()
![Cermet Circular Cold Saw Blade for Carbon Steels Cutting with Special Tooth Feature]()
![Cermet Circular Cold Saw Blade for Carbon Steels Cutting with Special Tooth Feature]()
![Cermet Circular Cold Saw Blade for Carbon Steels Cutting with Special Tooth Feature]()
PRODUCT DESCRIPTION
Production Information
| Application | For high carbon steel cutting |
| Equipment | High precise cold saw machine |
| RPM | V=70-100m/min |
| The amount of cut per tooth | Bar FZ=0.04-0.07 Tube FZ=0.03-0.06 |
| Material | C≤0.75% Carbon steel, Alloy steel |
| Tips | Cermet alloy |
| Features |
1. Customized steel plate with rare alloy 2. Cermet alloy teeth 3. Special angle design 4. Perfect straight cutting Mirror surface 5. Durable |
Cutting Amount and Cutting Speed
■ Cutting Amount Per Tooth(fz)
| Fz (mm/blade)=F/N*Z |
| Fz: The amount of cut per tooth |
| F: Feed speed (mm/min) |
| N: Equipment spindle speed (rpm) |
| Z: Number of teeth |
■ Recommended Parameters
| Bar Fz=0.04~0.07 (mm/blade) |
| Pipe Fz=0.03~0.05 (mm/blade) |
■ Cutting Speed (Saw Blade Line Speed) (v)
| V(m/min)=π*D*N/1000 |
| V: Cutting line speed (m/min) |
| D: Outer diameter (mm) |
| N: Equipment spindle speed (rpm) |
■ Recommended Parameters
| Medium and low carbon steel V=100~130 (m/min) |
| High carbon, alloy steel V=70~100 (m/min) |
Specification
| 1 | 285 | 32 | 2 | 120 | 285*32*2.0*120 |
| 2 | 315 | 32 | 2.25 | 60 | 315*32*2.25*60 |
| 3 | 315 | 32 | 2.25 | 72 | 315*32*2.25*72 |
| 4 | 315 | 32 | 2.25 | 80 | 315*32*2.25*80 |
| 5 | 315 | 32 | 2.25 | 100 | 315*32*2.25*100 |
| 6 | 315 | 32 | 2.25 | 120 | 315*32*2.25*120 |
| 7 | 315 | 32 | 2.25 | 140 | 315*32*2.25*140 |
| 8 | 360 | 40 | 2.6 | 60 | 360*40*2.6*60 |
| 9 | 360 | 40 | 2.6 | 72 | 360*40*2.6*72 |
| 10 | 360 | 40 | 2.6 | 80 | 360*40*2.6*80 |
| 11 | 360 | 40 | 2.6 | 100 | 360*40*2.6*100 |
| 12 | 360 | 40 | 2.6 | 120 | 360*40*2.6*120 |
| 13 | 380 | 40 | 2.6 | 60 | 380*40*2.6*60 |
| 14 | 380 | 40 | 2.6 | 72 | 380*40*2.6*72 |
| 15 | 380 | 40 | 2.6 | 80 | 380*40*2.6*80 |
| 16 | 380 | 40 | 2.6 | 100 | 380*40*2.6*100 |
| 17 | 400 | 50 | 2.7 | 50 | 400*50*2.7*50 |
| 18 | 400 | 50 | 2.7 | 60 | 400*50*2.7*60 |
| 19 | 400 | 50 | 2.7 | 80 | 400*50*2.7*80 |
| 20 | 400 | 50 | 2.7 | 100 | 400*50*2.7*100 |
| 21 | 425 | 50 | 2.7 | 40 | 425*50*2.7*40 |
| 22 | 425 | 50 | 2.7 | 60 | 425*50*2.7*60 |
| 23 | 425 | 50 | 2.7 | 80 | 425*50*2.7*80 |
| 24 | 425 | 50 | 2.7 | 100 | 425*50*2.7*100 |
| 25 | 460 | 50 | 2.7 | 40 | 460*50*2.7*40 |
| 26 | 460 | 50 | 2.7 | 60 | 460*50*2.7*60 |
| 27 | 460 | 50 | 2.7 | 72 | 460*50*2.7*72 |
| 28 | 460 | 50 | 2.7 | 80 | 460*50*2.7*80 |
| 29 | 460 | 50 | 2.7 | 100 | 460*50*2.7*100 |
| 30 | 460 | 50 | 2.7 | 120 | 460*50*2.7*120 |
| 31 | 458 | 50 | 2.7 | 60 | 485*50*2.7*60 |
| 32 | 485 | 50 | 2.7 | 72 | 485*50*2.7*72 |
| 33 | 485 | 50 | 2.7 | 80 | 485*50*2.7*80 |
| 34 | 485 | 50 | 2.7 | 100 | 485*50*2.7*100 |
| 35 | 520 | 50 | 3 | 60 | 520*50*3.0*60 |
| 36 | 520 | 50 | 3 | 72 | 520*50*3.0*72 |
| 37 | 520 | 50 | 3 | 80 | 520*50*3.0*80 |
| 38 | 560 | 50 | 3 | 60 | 560*50*3.0*60 |
| 39 | 630 | 80 | 3.4 | 60 | 630*80*3.4*60 |
| 40 | 630 | 80 | 3.4 | 72 | 630*80*3.4*72 |
| 41 | 630 | 80 | 3.4 | 80 | 630*80*3.4*80 |
| 42 | 630 | 80 | 3.4 | 100 | 630*80*3.4*100 |
ADVANTAGES
1. Advanced production & detection equipments and strict quality control system to ensure quality excellent and stable.
2. High cost effective saw blades with long life helping customer save more money.
3. Low noise, smooth cutting surface, no bur, no deformation and constantly teeth .
4. Special tooth design, cutting fast.
SPECIFICATION
