3Phase Vacuum Transformer Oil Purifier Plant Double Stage

Under effect of heat and electric field, the exposure of insulation oil contained trace water, gas and particulate matters etc.

The use of Vacuum Transformer Oil Purification and Regeneration Plant (Model SINO-NSH VFD-R) is necessary, which will help you maintain optimal oil cleanliness. Therefore, making the most use of your equipment to gain the highest and save your money.


General

Vacuum Transformer Oil Purification and Regeneration Plant is adapted to regenerate and activate the deteriorated transformer oil
It is capable of removing the moisture, gas and mechanical impurities as well as eliminating organic acid, sludges, pitches and dissociated carbon in the deteriorated transformer oil which are difficult to be removed by conventional oil purifier plants. After the treatment, the regenerated oil can meet the required standard and life span of new insulation oil.


Benefits of Transformer Oil Purifier

1. Removes Dissolved Moisture Transformer Oil
2. Reduces combustible gases and oxygen
3. Improves oil dielectric values
4. Improves transformer power factor
5. Extends oil service life
6. Extends transformer service life and reliability

Oil Data After Purification

OIL SPEC (after treatment)
● Dielectric: ≥ 75kV
● Water: ≤ 5 PPM
● Filter Fineness: ≤ 5 µm (or ≤ 1 µm)
● Degassing: ≤ 0.1%

With REGENERATION DEVICE, the machine can also treat acid, sludges, carbon and remove color.
● Oil color: better than L=0.5
● Acid Value: ≤ 0.01 MgK0H/g
● Soluble Acid PH value: =5~7
● Dielectric loss tangent tg(90℃)% : ≤0.002


Machine Specification
