Mobile Vacuum Transformer Oil Purifier Machine For Dehydration Degassing
PRODUCT OVERVIEW
Under effect of heat and electric field, the exposure of insulation oil contained trace water, gas and particulate matters etc.
The use of Vacuum Transformer Oil Purifier (SINO-NSH VFD series) is necessary, which will help you maintain optimal oil cleanliness. Therefore, making the most use of your equipment to gain the highest and save your money.
Application of Transformer Oil Purifier
NSH VFD series is mainly used to improve the properties of insulation oil. It can remove trace water, gas, particulate matters etc. from the insulating oil effectively and rapidly so as to boost performance of transformers, circuit breakers, mutual inductors, cable and capacitors which has insulation system. VFD series specialize in purifying branded oil, insulating oil of high voltage and super high voltage transformer. Additionally, it is suitable for treating low viscosity lubrication oil.
| Item | Unit | VFD-30 | VFD-50 | VFD-75 | VFD-100 | VFD-150 | VFD-200 | VFD-300 | |
| Flow Rate | L/H | 1800 | 3000 | 4000 | 6000 | 9000 | 12000 | 18000 | |
| Vacuum Range | MPa | －0.092～～－0.099 | |||||||
| Working Pressure | MPa | ≤ 0.3 | |||||||
| Max Vacuum Range | Pa | ≤ 50 | |||||||
| Temperature Range | ℃ | 45--85 | |||||||
| Water Content | PPm | ≤ 4 | |||||||
| Gas Content | % | ≤ 0.1 | |||||||
| Power Supply | V | ~50Hz 380V(or as needed) | |||||||
| Working Noise | dB | ≤ 72 | ≤ 78 | ||||||
| Heating Power | Kw | 24 | 30 | 48 | 72 | 108 | 144 | 210 | |
| Total Power | Kw | 26 | 33 | 58 | 76 | 114 | 150 | 222 | |
| Inlet Diameter | Mm | DN25 | DN25 | DN32 | DN32 | DN40 | DN50 | DN65 | |
| Outlet Diameter | Mm | DN25 | DN25 | DN32 | DN32 | DN40 | DN50 | DN65 | |
| Net Weight | Kg | 350 | 480 | 620 | 750 | 1100 | 1250 | 1420 | |
| Size | length | Mm | 1400 | 1500 | 1560 | 1800 | 1900 | 2000 | 2100 |
| width | Mm | 1000 | 1250 | 1260 | 1400 | 1650 | 1700 | 1700 | |
| height | Mm | 1200 | 1300 | 1500 | 1500 | 1800 | 1850 | 2 | |
1. Fixing station type, mobile type with four wheels and mobile type with trailer.
2. Normal appearance type, shelf-covering type and explosion-proof type.
3. Available in different color.
Edges
Double Axle Trailer and Single Axle Trailer
- Two wheels, four wheels, and multiple wheels are available.
- Well formed chassis
- Fast speed, 40km/h, the fast speed could be 80km/h
- The main body and chassis can be easily separated.
- Mobile hooking device, 360°rotary plate.
- Reliable air brake, oil brake and hand brake systems.
- Shockproof mount.
Steel Shield Type:
- Simple portability.
- Energy-saving, noise eliminating, rainproof
- Various sizes and configuration, outdoor work
- Anti-corrosion, good sealing performance
- All color available
