Automatic Control Vacuum Turbine Oil Purifier / Turbine Oil Filter Machine
PRODUCT OVERVIEW
Specifications
Sino-NSH-TF-A is a fully automatic dehydration and degassing unit. It could be tailored according to practical usage of end-user on either functional or operative consideration.
Sino-NSH-TF-A utilizes the brand Programmable Logic Controller (P.L.C.) and a series of instrumentations, alarms and interlocks to provide a fully automatic operation. Manual control of various functions is provided as required. Several Pilot Lights are provided to indicate operational status of key components and alarm conditions.
Sino-NSH-TF-A is particularly suitable for purifying turbine lubricating oil. It also applies to treat hydraulic, coolant oil and other lubrication in which contain large amount of water and others such as vapor, impurities, sludge, dielectric and colloid.
Features
1. Eliminate soluble and dissolved water effectively and demulsify rapidly.
TF series can not only separate large quantity of water but also remove trace of water from oil. Fitted with specially made demulsifying device (water separator), it is capable of making turbid emulsified oil very clear.
2. High effectively purify matters in oil such as impurities, sludge etc.
The automatic backwash filtering system can remove large number of particulate matters and fine filter system can remove tiny particles.
3. High automation, stability and operation online High automation, small size, light weight, safety and reliability. Installed with infrared liquid level automatic controller, the purifier machine will run automatically and easy handling.
| Water Content | ppm | ≤ 100 |
| Cleanliness | NAS 1638 | ≤ 6 |
| Impurity Size | μm | ≤ 5 |
| Emulsification Value | min | ≤ 15 |
| Machine Specification | ||||||||||
| Item | Unit | TF-20 | TF-30 | TF-50 | TF-75 | TF-100 | TF-150 | TF-200 | TF-300 | |
| Flow Rate | L/H | 1200 | 1800 | 3000 | 4500 | 6000 | 9000 | 12000 | 1800 | |
| Vacuum Range | MPa | －0.06～～－0.096 | ||||||||
| Working Pressure | MPa | ≤ 0.3 | ||||||||
| Water Ratio | PPm | ≤ 100 | ||||||||
| Impurity size | µm | ≤ 5 | ||||||||
| Clearness | NAS | ≤ 6 | ||||||||
| Temperature Range | ℃ | 40-80 | ||||||||
| Demulsifying Value | Μin | ＜ 15 | ||||||||
| Power Supply | V | Fully customizable | ||||||||
| Working Noise | dB | ≤ 70 | ≤ 75 | |||||||
| Heating Power | Kw | 15 | 24 | 32 | 40 | 48 | 72 | 96 | 120 | |
| Total Power | Kw | 18 | 27 | 32 | 40 | 53 | 78 | 103 | 129 | |
| Inlet(Outlet)Diameter | Mm | 25 | 25 | 32 | 35 | 40 | 50 | 65 | 65 | |
| Net Weight | Kg | 300 | 300 | 450 | 550 | 650 | 750 | 900 | 1500 | |
| Size | length | Mm | 1300 | 1300 | 1450 | 1550 | 1650 | 1850 | 2000 | 2400 |
| width | Mm | 900 | 900 | 1000 | 1100 | 1150 | 1250 | 1350 | 1700 | |
| height | Mm | 1460 | 1460 | 1510 | 1510 | 1560 | 1610 | 1660 | 1760 | |
Presentations Options
● Base frame with caster wheels
● Metallic enclosure cover on caster wheels
● Metallic enclosure cover on single-axle trailer
● Base frame on double-axle trailer
● Metallic enclosure cover on double-axle trailer
● Metallic enclosure cover and operation room on double-axle trailer.
Sino-NSH Oil Purifier Manufacture Co., Ltd. is a high-tech Company Since 1992 which is engaged in researching, developing and manufacturing lubrication purification equipment, Our products are very popular, if you are interested in our products, please contact us as soon as possible.
