3 Stages Short Path Vacuum Distillation Equipment CE ISO Approved
Below a distillation plant for laboratory use is described.
The plant may be used for:
• Process development
• Feasibility studies
• Continuous distillation of smaller quantities
For heat sensitive chemical, pharmaceutical or food products.
|
Technial Parameter :
|
|
|
|
Processing Measure(Depending on the material)
|
3~315L/h
|
|
|
Evaporator surface
|
0.1㎡
|
|
|
Inner condenser surface
|
0.15㎡
|
|
|
Scraping film system
|
scraper type scraping film rotor
|
|
|
Feeding
|
jacketed 1L glass funnel
|
|
|
feeding type
|
High precision gear pump with flow rate 3~15L/h
|
|
|
Receiving
|
5000ml *2 glass collecting flask
|
|
|
Maximum distillation temperature
|
300℃
|
|
|
Observation window
|
2 pcs for cold trap
|
|
|
Condenser quantity
|
1 pc
|
|
Packing:
-Standard wooden case.
-Both neutral and customized packaging can be available.
Shipping:
-We can ship the goods to you by International Express such as DHL,UPS,TNT,EMS and so on, you can also choose the appropriate one based on your timeline and budget. Besides,you can choose to use your own forward.
TOPTION as a professional lab solution provider is devoted to provide the best solutions & products for global customers, who are work in chemistry, biology, pharmaceutical, environment analysis, food, academic research, etc. Regardless of the field you work in, we keep striving for the same goal: to provide you with the most suitable solutions & products, to make your research more accurate & efficient.
We are professional manufacture of lab equipment and we have our own factory. And welcome to visit our factory.
2.Q:What's the processing capacity do you have?
We can offer you 1~3L/H, 5~12L/H, 10~25L/H, 18-30L/H, 20~60L/H.
3.Q: Can you do OEM service ?
A: We can provide the specific products needed around the world at significantly lower costs.
TOPTION also offers a Private Labeling Program to provide high quality lab supplies at lower prices.
If you need further information regarding our OEM or Private Label programs, please contact us freely.
4.Q: How long is your delivery time?
A: Usually, delivery time is 30-45 days after receiving your payment.
5.Q: How about your quality warranty ?
A: Normally all TOPTION products are supplied with a warranty of 12 Months from the date of shipment.
6. Q:Can we visit your factory?
A: Welcome visit our factory.
7. Q:If we want to customize molecular distillation , is it available?
Sure,we are experienced at this,we have professional technical team, we can design the drawing according to your requirements and then produce it.
