Automatic Lifting Industrial Vacuum Rotary Evaporator 20L ISO & CE Certified
Vacuum Rotary Evaporator 20L
20L industrial rotary evaporator ISO & CE certified manufacturer, RE-5220ADex rota evaporator is equipped with explosion proof system of motor, controller and bath. Is an idea instrument for concentration, drying and recycling.
Technology Parameters Of Vacuum Rotary Evaporator 20L
| Relevant Model | RE-5220ADEX |
| Evaporating Flask(L) | 20L/F125 |
| Receiving Flask(L) | 10L + 3L, bottom discharge |
| Condensing Surface(㎡) | 1 |
| Rotation Speed (rpm) | 3-110 |
| Evaporating Speed (H2O) | 5L/H |
| Lifting Type | Automatic lifting |
| Reachable Vacuum Rate | ＜133Pa (1.33mbar, 1 Torr) |
| Bath Power (kw) | 5 |
| Staic Temp. Control Range & Wave (℃) | RT-99(150) ±0.2 |
| Bath Size. Capacity Material | ￠35*25H, 22L, SUS304 |
| Power | 220V, 50/60Hz |
| Dimensions (cm) | 110*60*210H |
Safety features of 20L industrial rota evaporator:
| Relevant Model | RE-5220ADEx |
| Over-current Protection | Have |
| No-spark Electronic Control | Have |
| Ex-proof Upgrade | Ex-proof modification on motor, rotation & heating control, lower heating power density, equip dry heat and overheat cut-off protector |
Basic configuration of TOPTION 20L rotary evaporator:
| Relevant Model | RE-5220ADEx |
| Charging Valve | Glass |
| PTFE Discharge Valve | PTFE |
| PTFE Rotary Seal Assembly | Have |
| Overall Flange Joints | Have |
| Taper Joint PTFE Sleeve | Have |
| Frequency Conversion Speed Control | Have |
| Vacuum Meter | Have |
| Throttle Valve For Vacuum | Have |
| Thermometer Neck For Vapor | Optional |
| Continuous Receiving | Have |
| Digital Display | Bath temperature, Rotation speed |
| Evaporating Flask Unload Handler | Optional |
| Ex-proof Motor | Optional |
| Cold Trap Protection System | Optional |
| Bumping System | Have |
| Optional Evaporating Flask (baffles available at request) | 5L, 10L |
Features Of Vacuum Rotary Evaporator 20L
1.Adopt advanced frequency converter and electronic speed regulator to ensure the stable working of motor and improve the evaporation and recovery speed.
2.Automatic bath lift and and vacuum feeding can help to reduce the breakage of rotary flask.
3.Receiving flask use ball-milling port for connection to ensure the high sealing, it also can be removed easily.
4.Use high temperature resistant, corrosion resistant and long-acting precision seals to ensure the gas tightness
under high temperature, high negative pressure and strong corroding conditions when it is under dynamic sealing.
5.Adopt AC induction motor, variable speed, no brush, no spark, can work effectively for a long time.
6.Chassis, bath pot, main bar, shaft of rotary evaporator are made of high qualified stainless steel, appearance is attractive and anti-corrosive.
7.Intelligent temperature controller, can work with both water and oil bath, more widely used. Temperature fluctuation is only ±0.02 ℃. Evaporation is more stable and material can not be washed easily.
CE Certification Of Industrial Rotary Evaporator 20L
ISO9001:2008 & CE quality certification, products' quality management system, for every delivery instrument, we
have professional quality manager team to cheak, then sign product certification and warranty card. Protect your research and business safe.
TOPTION as a professional lab solution provider is specialized in manufacturing and selling photochemical glass
reactor , ice maker, ultrasonic instrument, spray dryer, air dryer,extracting device and so on, who are work in chemistry,environment analysis, food, academic research, etc. Regardless of the field you work in, we keep striving for the same goal: to provide you with the most suitable solutions & products, to make your research more accurate & efficient.
