Stainless Steel Ultrasonic Dispersion Equipment Ultrasonic Dispersion Machine
Stainless Steel Ultrasonic Material Dispenser Ultrasonic Cavitation Treatment
Ultrasonic material dispenser is also popular as ultrasonic emulsification reactor, stainless steel ultrasonic reactor, which through its "cavitation effect" to realize the emulsification of oil blended with water, emulsification of water mixed with oil, the mixture and homogenization of dispersed phase and continuous phase, it's modern chemical technology to instead of propeller, colloid mill and other traditional emulsification technology.
| Model |
TUER-5SUS / TUER-5SUD |
TUER-10SUS / TUER-10SUD |
TUER-20SUS / TUER-20SUD |
| Ultrasound Method | Energy-gathered circulation multiple-step type | ||
| Capacity(L) | 5 | 10 | 20 |
| Stir Motor Power(W) | 100 | 150 | 200 |
| Ultrasonic Frequency | 20KHz | 20KHz | 20KHz |
| Standard Ultrasonic Probe | ￠20*1 | ￠20*2 | ￠20*3 |
| Ultrasonic Power(w) | 50~1200 Adjustable | 100~2400 Adjustable | 200~3600 Adjustable |
| Circulation Stirring Rate (rpm) |
0~1000 Integrated Digital Display, Stepless Timing |
0~1000 Integrated Digital Display, Stepless Timing |
0~1000 Integrated Digital Display, Stepless Timing |
| Controlled Temperature ℃ (Optional) |
0--100 | 0--100 | 0--100 |
| Reactor Material | SS304/Glass | SS304/Glass | SS304/Glass |
| Applicable Medium |
Volatility / Fixed Hydrocarbon |
Volatility / Fixed Hydrocarbon |
Volatility / Fixed Hydrocarbon |
| Application | Laboratory & Pilot | Laboratory & Pilot | Pilot |
|
Note: Professional Customization is provided, high temp. device, low temp. device, constant temp. device are available (-5℃ ~ 100℃). Model: S - stainless steel material; U- "U" shape design; S - single layer; D - double layer. |
|||
