Precise Air Drying Oven Lab Drying Equipment Microcomputer Control

• • Precise air drying oven is applied in industrial and mining enterprises, laboratory, R&D institution and other places for desiccation, baking dewaxing and sterilization.

    Main features of drying oven precise air drying oven lab drying equipment:

1. Several sets of data shows in a big LCD screen. The operation interface can be easily understood and operating.

2. German-imported blower, lifetime can be lengthened twice over.

3. Blower's fast and slow speed control mode, temperature uniformity can be improved.

4. Unique air duct system, no manual adjustment any more. Vapor can be released automatically.

5. Over temperature deviation protection and microcomputer PID controller, quick achieve to the design temperature with steady operation.

• 6. Microcomputer control with timing, accurate and reliable.



  7. Stainless-steel chamber, semicircular arcs at corners for easy cleaning, and the space between the shelves can be set by the customer.



  8. Thickened design of wall and the door protects user’s safety even after continuous using of the oven.



  9. Sealing design of a new type synthetic silicon sealing stripe prevents heat loss effectively, assembly units' service life can be lengthened on the basis of 30% energy saving.



  10. Independent alarm system for temperature-limiting, automatically interrupt operation when exceeding the limit. Ensure the safety of the experiment. (optional)



  11. RS485 interface may link the recorder and the computer, records the changes of temperature parameter.(optional)

•

  Technical parameters of drying oven precise air drying oven lab drying equipment:

  Items	Supply voltage	Temperature control range	Constant temperature fluctuation	Temperature resolution	Input power	Studio dimension W×D×H(mm)	Boundary dimension W×D×H(mm)	Volume
  BPG-9040A	AC220V 50HZ	RT+10 ~ 300℃	±0.5℃	0.1℃	850W	300×300 ×345	445×470 ×700	40L
  BPG-9050A		100℃ ~ 400℃			2500W	350×350 ×400	695×600×640	50L
  BPG-9070A		RT+10 ~ 300℃			1100W	400×425 ×445	545×580 ×800	80L
  BPG-9100A		100℃ ~ 400℃			3000W	450×450 ×450	795×700×690	100L
  BPG-9140A		RT+10 ~ 300℃			1550W	450×550 ×550	640×710 ×905	136L
  BPG-9200A		100℃ ~ 400℃			4500W	600×600 ×600	945×850×840	200L
  BPG-9240A		RT+10 ~ 300℃			2050W	500×600 ×750	680×800 ×1205	225L
  BPG-9420A	AC380V 50HZ				3500W	600×550 ×1300	780×750 ×1850	420L
  BPG-9620A					4000W	800×640 ×1290	980×750 ×1750	620L
  BPG-9920A					6000W	1000×600 ×1600	1180×800 ×2150	1000L
