High Temperature Laboratory Blast Drying Oven With RS485 Interface

TOPTION high temperature blast drying oven laboratory drying oven is widely used in industrial & mining enterprises, test, scientific research institution,etc.

For drying, baking, wax-melting and sterilization, this type high temperature blast drying oven could help you achieve these.

1. Studio use high quality steel or stainless steel material.

2. Microcomputer intelligent temperature controller which has setting, measuring temperature double digital display, timing,power restrain and self-adjusting function, temperature control accurate and reliable.

3. Hot air circulation system consists of low noise fan and air duct, which effectively guarantee the studio inner temperature uniformity.

4. Independent temperature limitation alarm system, it will be automatically interrupted if over the limit temperature, so as to guarantee the safe of experiment and operation without any accident.(Optional).

5. With RS485 interface which could connect the recorder and computer, so could record the change situation of temp. parameters.(Optional)

• • TOPTION high temperature blast drying oven laboratory drying oven technical parameters:





• • Items	HHG -9078A	HHG-9148A	HHG-9248A	HHG-9079A	HHG-9149A	HHG-9249A
    Supply voltage	AC220V 50HZ
    Temperature control range	RT+20~400℃			RT+30~500℃
    Constant temperature fluctuation	±2℃
    Temperature resolution	1℃
    Input power	2050W	2500W	3000W	3400W	4400W	5500W
    Studio dimension W×D×H(mm)	400×400×450	450×550×550	500×600×750	400×400×450	450×550×550	500×600×750
    Volume	70L	140L	240L	70L	140L	240L
    Loading bracket (Standard configuration)	2pcs
    * Performance parameters under idle condition, no strong magnetic and no vibration: environment temperature 20℃, environment humidity 50%RH.

  •
