250ml Laboratory Heating Mantle Intelligent Digital Display Customized

Description

250ml thermostat heating mantle is an intelligent digital display thermostat heating mantle, which is is an ideal instrument for laboratory high precise temperature control heating experiment.

• 1.Thermostat heating mantle use alkali-free glass fiber as insulating material, put Cr20Ni80 alloy wire in it, use aluminum silicate wool shaped hemispheric temperature protection device under vacuum condition.



  2.Heating mantle shell is one-time punch forming, upper lid use electrostatic coating process, could make vessels heating surface reach over 60% as use spherical heating method.



  3. Temperatture control use computer chip as main control unit, multiple digital filter circuit, fuzzy self-adaptive PID control arithmetic, self-adjusting function.





  • These features make heating mantle own absolutely advantages:


    1. High precise temperature measure, small temperature rush.



    2. Easily single key operating, double screen display, thermocouple measure temp., silicon controlled control output.



    3.160V-240V wide voltage power source range, with disconnection protection system, heating quickly, high temperature, convenient & easily operation, long service life.



    So intelligent digital display thermastat heating mantle is an ideal instrument for laboratory high precise temp. control heating experiment.

• Power source	220v 50hz (110v 50/60hz is available)
  Capacity	250ml
  Power	210W
  Temp. control accuracy	±1℃ Controlled silicon control Sensor temp. sensing Self-adjustable function
  Heating temp.	Max surface temp. 380℃
  Boiling	250ml water 10-25min
  Furnace wire	Cr20Ni80
  Insulating layer	Alkali-free glass fiber,temp. resistance 450℃
  Insulating coefficient	Relative humidity≤35%, ≥500MB
  Temp. protect layer	Aluminum silicate wool vacuum shaped environment friendly temp protector
  Diameter of upper mouth	95mm
  Mantle depth	60mm
  Shell diameter	230mm
  Shell height	155mm
  Weight	1300g+50g
