High Frequency PCB Built on Shengyi SCGA-500 GF265 PTFE with Glass Reinforced RF Circuit Materials

(Printed Circuit Boards are custom-made products, the picture and parameters shown are just for reference)

Brief Introduction

SCGA-500 GF265 from Shengyi Technology Co., Ltd (SYTECH) is low loss PTFE woven glass UL 94 V-0 high frequency circuit material. It has been designed for use in many of today’s demanding and highly challenging RF/Microwave design platforms.

Its controlled dielectric constant provides excellent electrical and mechanical properties with a consistent and stable DK (2.55Dk +/- 0.04) and dissipation factor (0.0014) over a wide range of frequencies (1GHz to 20 GHz) and Temperatures (-40 °C to +125 °C).

It exhibits exceptional dimensional stability, chemical resistance, low moisture absorption and copper peel strength. Passive Inter-Modulation (PIM) performance values -163 dBc are typical (RTF and VLP type copper foils).

SCGA-500F GF265 is an excellent choice for high volume manufacturing requirements where a balance of cost and performance are of paramount importance.

Features

1. Consistent and Stable Dk/Df over Frequency and Temperature

2. Low Dielectric Loss Tangent

3. Excellent Price Performance Value

Typical applications

1. Base Station Antennas

2. Power Amplifiers

3. Satellite Communications

4. DAS and CPE Antenna

5. Automotive Radar and Wireless Communications.
