Aluminum Non Polar Electrolytic Capacitor 100uF 63V For High Frequency
Non-Polar Aluminum Electrolytic Capacitor 100uF 63V for High Frequency
Features
Load life of 2,000 hours at 85C.
Bi-polar,low dissipation factor and stable temperature characteristics
Allowing high frequency and high ripple current
Having safety vents
| TOPMAY P/N | Specification |
| TMCE07-107M63VP5B | Radial 100uF 63V 13*20 |
Product Standard:
| Specification size(mm) | Physical characteristic | |||||||
| D | L | F | d | Cap.Tolerance | D.F(%) | L.C(µA) | Max RC(mA) at 120Hz 105℃ | Max ESR(Ω) at 120Hz 25℃ |
| 13 | 20 | 5.0 | 0.6 | ±20% | ≦20 | ≦192 | 390 | 2.65 |
Marking Unless otherwise specified, Capacitor shall be clearly marked on it body.
(1) Brand TOPMAY
(2) Sleeve BlACK(PVC)
(3) Polarity:NON Polarity
(4) Type : Radial
(5) Series:NP
(6) Nominal capacitance 100µF
(7) Rated voltage 63V
(8) Surge voltage 79V
(9)Temperature Range -40~+ 85℃
(10) Life 2000 hours
(11) Lead wire CP wire
FAQ Of Topmay Capacitor
1) Can I have a free sample to test ?
Yes, we could provide free samples to test and check quality. Freight cost is collected.
2) What is the lead time?
Sample needs about 7~10 working days prepared; mass production average time takes 15-20 working days
3) Do you have any MOQ limit?
Yes. But it depends on product. Normally MOQ is 2K~10Kpcs
4) How about price terms?
We do FOBSHENZHEN if order amount is more than 5000USD. Less than that, it is EXWSHENZHEN and we do not undertake local charge.
5) What information should I let you know if I want to get a quotation?
Basically for capacitor, it requires to know detailed capacitance and voltage. If you have more information, such as type, product photo for reference, you could kindly provide too.
