High Purity 7.19g/Cm3 Chromium Sputtering Target PVD Coating
Product description
Chromium targets produced by Achemetal Tungsten & Molybdenum Co., Ltd. include chromium plane targets and chromium-niobium rotating targets.
The purity respectively includes: Cr99.5%,Cr99.7%,Cr99.8%,Cr99.9%,Cr99.95%.
Features of targets manufactured by Achemetal:
Due to the adoption of a hot isostatic pressing process, the product features high density, good compactness and uniform crystal grains.
Higher machining property
Relative density of targets: over 99%, relative density of alloy: over 97%; grain size: less than 50um; thermal resistance of films: below 5%; welded rate with back plates: over 98%, film uniformity after target film formation: over 95%
Product specifications
| Chromium Target Parameters | ||
| Elements | Cr | |
| Purity | >99.5%(2N5) | |
| Sample size | Φ127mm×15mm | |
| Density | 7.19 g/cm3(HIP) | |
| Hardness | HV5:162-166 | |
| Grain size | 13μm | |
| Surface roughness | Ra≤0.4μm | |
| Impurity content (powder) | Fe | ≤1200ppm |
| Al | ≤1700ppm | |
| Si | ≤1400ppm | |
| S | ≤10ppm | |
| C | ≤60ppm | |
| O | ≤900ppm | |
| P | ≤30ppm | |
| Cu | ≤20ppm | |
| N | ≤100ppm | |
Note: all the specifications can meet the requirement of customers on high accuracy through machining.
| 2N5 Trace elements PPM ≥7.19 g/cm³ | |||||||||
| Chemistry | Fe | Al | Si | Cu | Pb | C | S | O | N |
| Standard | ≤1500 | ≤1200 | ≤1500 | ≤30 | ≤30 | ≤100 | ≤50 | ≤1000 | ≤100 |
| Test Value | 1300 | 700 | 1000 | 20 | 3 | 60 | 7 | 900 | 60 |
Production details
Product application
Our chromium targets are mainly applied to:
Thin-film solar industry, touch control industry, glass industry, semiconductor industry, optical coatingindustry, surface decoration and tool coating industry.
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-7 work days if the goods are in stock. Or it needs 15-20 work days after the order is placed.
Q: Do you provide samples ?
A: Yes, We provide samples for free.
Q: What is your terms of payment ?
A: T/T is better.
If you have other question, please don't be hesitated to contact me.
