ASTM B392 Niobium Metal Niobium Plate Excellent Acid Resistance
Manufacturers wholesale various sizes high-purity niobium plate and niobium alloy plate
Product Description
At room temperature, niobium does not react with air and is not completely oxidized when red hot in oxygen. Niobium can be directly chemically combined with sulfur, nitrogen and carbon at high temperatures. Niobium does not react with inorganic acids or bases and is insoluble in aqua regia, but is soluble in hydrofluoric acid. Niobium is present in the earth's crust at a level of 20 ppm and the distribution of niobium resources is relatively concentrated. Due to its good superconductivity, high melting point, corrosion resistance and wear resistance, niobium is widely used in steel, superconducting materials, aerospace, atomic energy and other fields.
Feature
1. Good ductility
2. Good plasticity
3. Excellent acid-resistance
4. High melting point, high boiling point
5. Very small coefficients of thermal expansion
6. Good capability of absorbing and releasing hydrogen
Application
1.Electronic Instrument
2.Industry Steel industry
3.Chemical industry
4.Atomic energy industry
5.Aerospace aviation
6.Cemented carbide
7.Medical treatment
| China manufacturer refractory metal supplier pure niobium plate | |
| Material | Pure niobium |
| Grade | RO4200.RO4210,R04251,R04261 |
| Standard | ASTM B392 |
| MOQ | 1KG |
| Surface | Polished |
| Characteristic | Melting point : 2468℃ / Boiling point : 4744℃ |
| Density | 8.6 g/cm3 |
| Product Features | Excellent Corrosion Resistance , Good resistance to effect of heat ,Nonmagnetic and Non-toxic |
| Content, Max, Weight % | ||||
| Element | Grand: R04200 | Grand:R04210 | Grand:R04251 | Grand:R04261 |
| Unalloyed Niobium | Unalloyed Niobium | (Reactor grade niobium-1% Zirconium) | (Commercial grade niobium-1% Zirconium) | |
| C | 0.01 | 0.01 | 0.01 | 0.01 |
| O | 0.015 | 0.025 | 0.015 | 0.025 |
| N | 0.01 | 0.01 | 0.01 | 0.01 |
| H | 0.0015 | 0.0015 | 0.0015 | 0.0015 |
| Fe | 0.005 | 0.01 | 0.005 | 0.01 |
| Mo | 0.01 | 0.02 | 0.01 | 0.05 |
| Ta | 0.1 | 0.3 | 0.1 | 0.5 |
| Ni | 0.005 | 0.005 | 0.005 | 0.005 |
| Si | 0.005 | 0.005 | 0.005 | 0.005 |
| Ti | 0.02 | 0.03 | 0.02 | 0.03 |
| W | 0.03 | 0.05 | 0.03 | 0.05 |
| Zr | 0.02 | 0.02 | 0.8~1.2 | 0.8~1.2 |
| Nb | Remainder | Remainder | Remainder | Remainder |
Dimension Tolerance:
| Thickness mm | Width mm | Length mm |
| 0.05 ~ 0.10 | 100 | 600 |
| 0.10 ~ 0.15 | 100 | 800 |
| 0.15 ~ 0.20 | 200 | 800 |
| 0.20 ~ 0.30 | 300 | 1000 |
| 0.30 ~ 0.50 | 420 | 1200 |
| 0.50 ~ 1.0 | 550 | 1000 |
| 1.0 ~ 2.0 | 610 | 1000 |
| 2.0 ~ 3.0 | 500 | 1000 |
| > 3.0 | 400 | 800 |
Applications:
FAQ
Q1: How long is your delivery period?
A1: It depends on specific conditions. However, it could be 10 to 15 days on average.
Q2: Do you offer samples?
A2: Yes, we do offer samples. However, buyers need to pay for the freight charge. In addition, whether samples are free or not depends on the quantity you buy.
Q3: How do you pack the products?
A3: In general, we use wood, plastic or carton boxes. We also put some soft materials inside to prevent possible damage on products.
Q4: How much advance payment do I need to make?
A4: If the products you buy are in stock, you need to make full payment; if the products are out of stock, you need to make about 50 percent of full payment and then we will start the production process. However, you still need to pay the rest of charges before we deliver the products.
Q5: What kinds of payment do you accept?
A5: In addition to the patterns of payment shown above, you can discuss with us about in which way you would like to pay.
